Sharp R-342 Service Manual

Ref No. Midea Part No. Part Name&Description Pcs/Set Remarks
A01
252100100016
COVER WAVE GUIDE
1
T=0 35 118
*
99
A01
252100100016
COVER
WAVE
GUIDE
1
T=0
.
35
118*99
B01 261501409902 BASE PLATE 1 E25L SGCC T=0.6
B02 256302000004 LEG 4 A17L PP T30
B03 256502500868 ASS'Y BRKT HINGE *U 1 C23L SPCC T=2.5
C01 261300264700 PANEL CONTROL 1 E25L Silver
C05 261820902664 DECO. MEMBRANE 1
C07 261306014100 BUTTON DOOR OPEN 1 E25L Silver
C08 252010100001 SPRING BUTTON 1 17L
C13 251306103544 LEVER DOOR OPEN 1 C23L PBT
C18 261400124780 PCB ASS'Y 1 EMXEEXU-01-K
C26 261400209130 SWITCH CIRCUIT 1
C55 261515901000 SHIELD 1 SGCC T=0.5
D01 251500200108 ASS'Y DOOR FRAME 1 E25L SPCD T=0.6
D02 251300500046 LATCH 1 A28L
D03 252010000000 SPRING LATCH 1 25L
D04 256502400556 ASS'Y BRKT HINGE *T 1 A28L SPCC T=2.0
D05 252200400382 BARRIER SCREEN *I 1 E25L PET
D06
262100402834
BARRIER SCREEN *O
1
D06
262100402834
BARRIER
SCREEN
*O
1
D07 261300141101 PANEL DOOR 1 E25L Silver
D08 256300600075 GASKET DOOR 1 E28L Black
E01 251200100068 MAGNETRON 1 2M219J 900W
E05
251200200337
H V TRANSFORMER
1
E05
251200200337
H
.
V
.
TRANSFORMER
1
E06 251200701304 H.V.CAPACITOR 1 CH85 1.05uF 2100V
E07 251200900861 H.V.DIODE 1 12kV 350mA
REPLACEMENT PARTS LIST
NOTE:
When ordering replacement part(s), please use part number(s) shown in this part list.
Do not use description of the part.
F
R-342(IN)W
or Model:
MD-901EMR-1 WLC BWL-
900E 06A WB0253
900E
-
06A
WB0253
