R-405HK
R-405HW
R-403HW
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
PARTS LIST
Note: The parts marked “
∆∆
∆∆
∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION.
∆
ELECTRIC PARTS
1- 1 RC-QZB018MRE0 M High voltage capacitor 1 AQ
1- 2 FH-DZB013MRY0 M High voltage rectifier assembly 1 AK
1- 3 QSOCLB006MRE0 M Oven lamp socket 1 AE
1- 4 RLMPTA086WRZZ M Oven lamp 1 AD
1- 5 RMOTEA346WRE0 M Fan motor 1 AR
1- 6 FFS-BA019/KIT M
Monitor switch (V-16G-2C25), C/T fuse (20A 250V AC) & Inst.
1AF
1- 7 QSW-MA085WRE0 M
Primary interlock switch and door sensing switch (V-5230Q)
2AE
1- 8 QFS-TA014WRE0 M Cavity temperature fuse 150
O
C 1AF
1- 9 RV-MZA293WRE0 M Magnetron 1 BC
1-10 RMOTDA211/KIT M Turntable motor 1 AL
1-11 RTRN-B077MRE0 M Power transformer 1 BZ
1-12 FACCDB003MRE0 M Power supply cord 1 AM
CABINET PARTS
2- 1 GDAI-B068MRP0 M Base plate 1 AN
2- 2 GLEGPB004MRF0 M Foot 4 AB
2- 3 GCABUB097MRP0 M Outer case cabinet [R-405HK] 1 AT
2- 3 GCABUB088MRP0 M Outer case cabinet [R-403HW/R-405HW] 1 AU
CONTROL PANEL PARTS
3- 1 GPNLCB037/KIT M Control unit assy [R-405HK] 1 BA
3- 1 GPNLCB037/KITA M Control unit assy [R-405HW] 1 BA
3- 1 GPNLCB036/KIT M Control unit assy [R-403HW] 1 BA
3- 2 HPNLFB005MRF0A M Control panel frame [R-405HK] 1 AE
3- 2 HPNLFB007MRF0A M Control panel frame [R-405HW] 1 AE
3- 2 HPNLFB004MRF0A M Control panel frame [R-403HW] 1 AF
3- 3 PSHEPB114MRR0 M Graphic sheet [R-405HK] 1 AG
3- 3 PSHEPB124MRR0 M Graphic sheet [R-405HW] 1 AG
3- 3 PSHEPB115MRR0 M Graphic sheet [R-403HW] 1 AG
3- 4 JBTN-B151MRF0A M Open button [R-405HK] 1 AD
3- 4 JBTN-B155MRF0A M Open button [R-405HW] 1 AF
3- 4 JBTN-B150MRF0A M Open button [R-403HW] 1 AD
3- 5 MSPRCA045WRE0 M Open button spring 1 AA
3- 6 XEPSD30P06XS0 M Screw; 3mm x 6mm 5 AA
OVEN PARTS
4- 1 LBNDKB007MRP0 M H.V. Capacitor band 1 AB
4- 2 LANGTB060MRP0 M Chassis support 1 AD
4- 3 PHOK-B018MRF0 M Latch hook 1 AF
4- 4 MLEVPB016MRF0 M Switch lever 1 AD
4- 5 PDUC-B120MRF0A M Magnetron duct 1 AM
4- 6 NFANPB001MRE0 M Fan blade 1 AC
4- 7 PDUC-B088MRF0 M Fan duct 1 AC
4- 8 ------------- M Oven cavity (Not a replaceable part) 1 --
4- 9 PCOVPB073MRP0 M Waveguide cover 1 AC
4-10 PPACGB014MRF0 M Turntable motor packing 1 AA
4-11 PCUSUB033MRP0 M Cushion 1 AA
DOOR PARTS
5 -1 FCOV-B234MRK0 M Door frame assembly [R-405HK] 1 AW
5 -1 FCOV-B238MRK0 M Door frame assembly [R-405HW] 1 AW
5 -1 FCOV-B233MRK0 M Door frame assembly [R-403HW] 1 BB
5-1-1 LSTPPB021MRF0 M Latch head 1 AD
5-1-2 MSPRTA046WRE0 M Latch spring 1 AB
5 -2 FDORFB074MRT0 M Door panel 1 AQ
5- 3 PSHEPB021MRE0 M Sealer film 1 AE
5- 4 GCOVHB046MRF0 M Choke cover 1 AG
5- 5 LSTPPB044MRF0 M Door stopper 1 AA
5- 6 HPNL-B105MRE0 M Door screen [R-405HK] 1 AQ
5- 6 HPNL-B106MRE0 M Door screen [R-405HW] 1 AQ
5- 6 HPNL-B104MRE0 M Door screen [R-403HW] 1 AN
5- 7 JBTN-B152MRF0A M Door button [R-405HK] 3 AD
5- 7 JBTN-B156MRF0A M Door button [R-405HW] 3 AB
5- 8 MSPRTB022MRE0 M Button spring [R-405HK/R-405HW] 3 AC
5- 9 PCUSGB033MRP0 M Cushion [R-405HK/R-405HW] 1 AA
