R408LS
5
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[2] DOOR AND CONTROL PANEL PARTS
CONTROL PANEL PARTS
3-1 DPNLCC019WRKZ BF Panel med assembly
3-1-1 FBTN-A164WRKZ AP Open button assembly
3-1-1-1 JBTN-B391WRFZ AH Open button
3-1-1-2 HDECQA328WRPZ AM Button decoration
3-1-2 HDECQA329WRPZ AU Panel decoration
3-1-3 MSPRCA157WREZ AF Open button spring
3-1-4 PSHEPB238WREZ AM Key sheet
3-1-5 QSW-KA077DRZZ AQ FPC
3-2 DPWBFC563WRKZ BK Control unit
3-3 XEPS730P08XS0 AB Screw; 3mm x 8mm
DOOR PARTS
* 5-1 FDORFA412WRTZ BF Door panel
5-2 PSHEPA336WRP0 AF Sealer film
* 5-3 FWAKPA462WRKZ BE Door frame assembly
* 5-3-1 GWAKPB081WRFZ AX Door frame
5-3-2 HDECQA334WRRZ BB Door decoration
5-4 HPNL-A890WRRZ AP Door screen
* 5-5 GCOVHA382WRF0 AM Choke cover
* 5-6 LSTPPA139WRF0 AE Latch head
5-7 MSPRTA084WRE0 AB Latch spring
5-8 LSTPPA167WRF0 AG Door stopper
5-9 XEPS740P08000 AB Screw: 4mm x 8mm
MISCELLANEOUS
6-5 FW-VZC094WREZ AS Main wire harness
6-6 FW-VZC093WREZ AN Filter harness
6-7 TINSEB137WRRZ AL Instruction book
To Next Page
