R408LS
4 – 1
R408LS
Service Manual
CHAPTER 4. PRODUCT DESCRIPTION
[1] SPECIFICATIONS
ITEM DESCRIPTION
Power Requirements
120 Volts
60 Hertz
Single phase, 3 wire grounded
Power Consumption 1600W / Approx. 13.5 Amperes
Power Output
1100 W nominal of RF microwave energy (IEC Test procedure)
Operating frequency 2450 MHz
Outside Dimensions
Width 21-5/8"
Height 12-3/8"
Depth 17-1/2"
Cooking Cavity Dimensions
(1.4 Cubic feet)
Width 15-3/8" NOTE: Internal capacity is calculated by measuring
Height 9-3/8" maximum width, depth and height.
Depth 16-3/4" Actual capacity for holding food is less.
Control Complement
Touch Control System
Clock (1:00 - 12:59)
Timer (0 - 99 minutes 99 seconds)
Microwave Power for Variable Cooking
Repetition Rate;
P-HI -------------------- Full power throughout the cooking time
P-90 -------------------- approx. 90% of FULL Power
P-80 -------------------- approx. 80% of FULL Power
P-70 -------------------- approx. 70% of FULL Power
P-60 -------------------- approx. 60% of FULL Power
P-50 -------------------- approx. 50% of FULL Power
P-40 -------------------- approx. 30% of FULL Power
P-30 -------------------- approx. 40% of FULL Power
P-20 -------------------- approx. 20% of FULL Power
P-10 -------------------- approx. 10% of FULL Power
P-0 ---------------------- No power throughout the cooking time
POPCORN pad
MINUTE PLUS pad
Cook pad
Defrost pad
Reheat pad
Number selection pads
Power Level pad
Timer/Clock pad
Stop/Clear pad
START pad
Melt, Soften, Warm pads
Oven Cavity Light Yes
Safety Standard
UL listed FCC Authorized
DHHS Rules, CFR, Title 21, Chapter 1, Subchapter J
