38
R-426HS
R-426HK
R-426HW
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
PARTS LIST
Note: The parts marked “
∆∆
∆∆
∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION.
∆
ELECTRIC PARTS
1- 1 RC-QZB018MRE0 M High voltage capacitor 1 AQ
1- 2 FH-DZB018MRY0 M High voltage rectifier assembly 1 AU
1- 3 QSOCLB006MRE0 M Oven lamp socket 1 AE
1- 4 RLMPTA081WRZZ M Oven lamp 1 AD
1- 5 RMOTEA346WRE0 M Fan motor 1 AR
1- 6 FFS-BA019/KIT M
Monitor switch (V-16G-2C25), C/T fuse (20A 250V AC) & Inst. 1AF
1- 7 QSW-MA085WRE0 M
Primary interlock switch and door sensing switch (V-5230Q) 2AE
1- 8 QFS-TA014WRE0 M Cavity temperature fuse 150
O
C 1AF
1- 9 RV-MZA303WRE0 M Magnetron 1 BA
1-10 RMOTDA211WRE0 M Turntable motor 1 AL
1-11 RTRN-B069MRE0 M Power transformer 1 BC
1-12 FACCDB003MRE0 M Power supply cord 1 AM
1-13 FDTCTA198WRK0 M AH Sensor 1 AN
CABINET PARTS
2- 1 GDAI-B069MRP0 M Base plate 1 AP
2- 2 GLEGPB004MRF0 M Foot 4 AB
2- 3 GCABUB125MRP0 M Outer case cabinet [R-426HS] 1 AU
2- 3 GCABUB092MRP0 M Outer case cabinet [R-426HK] 1 AU
2- 3 GCABUB093MRP0 M Outer case cabinet [R-426HW] 1 AU
CONTROL PANEL PARTS
3- 1 GPNLCB034/KIT M Control unit assy [R-426HS/HK] 1 AY
3- 1 GPNLCB034/KITA M Control unit assy [R-426HW] 1 AY
3- 2 HPNLFB001MRF0A M Control panel frame [R-426HS/HK] 1 AD
3- 2 HPNLFB006MRF0A M Control panel frame [R-426HW] 1 AE
3- 3 PSHEPB109MRR0 M Key unit [R-426HS/HK] 1 AG
3- 3 PSHEPB119MRR0 M Key unit [R-426HW] 1 AG
3- 4 FDECAB037MRK0 M Open button [R-426HS] 1 AF
3- 4 JBTN-B146MRF0A M Open button [R-426HK] 1 AD
3- 4 JBTN-B153MRF0A M Open button [R-426HW] 1 AE
3- 5 MSPRTA050WRE0 M Open button spring 1 AA
3- 6 XEPSD30P06XS0 M Screw; 3mm x 10mm 5 AB
OVEN PARTS
4- 1 LBNDKB007MRP0 M H.V. Capacitor band 1 AB
4- 2 LANGTB058MRP0 M Chassis support 1 AD
4- 3 PHOK-B018MRF0 M Latch hook 1 AF
4- 4 MLEVPB016MRF0 M Switch lever 1 AD
4- 5 PDUC-B120MRF0A M Magnetron duct 1 AM
4- 6 NFANPB006MRE0 M Fan blade 1 AC
4- 7 PDUC-B088MRF0 M Fan duct 1 AC
4- 8 ------------- M Oven cavity (Not a replaceable part) 1 --
4- 9 PCOVPB085MRP0 M Waveguide cover 1 AH
4-10 PPACGB014MRF0 M Turntable motor packing 1 AA
4-11 PCUSUB033MRP0 M Cushion 1 AA
4-12 PDUC-B106MRP0 M Sensor duct 1 AA
DOOR PARTS
5 -1 CDORFB323MRK0 M Door frame assembly [R-426HS] 1 AP
5 -1 CDORFB328MRK0 M Door frame assembly [R-426HK] 1 AP
5 -1 CDORFB332MRK0 M Door frame assembly [R-426HW] 1 AP
5 -1-1 LSTPPB023MRF0 M Latch head 1 AC
5 -1-2 MSPRTA046WRE0 M Latch spring 1 AB
5 -2 FDORFB074MRT0 M Door panel [R-426HS/HK] 1 AW
5 -2 FDORFB080MRT0 M Door panel [R-426HW] 1 AW
5- 3 PSHEPB108MRE0 M Sealer film 1 AD
5- 4 GCOVHB046MRF0 M Choke cover 1 AG
5- 5 FCOV-B227MRK0 M Door screen [R-426HS] 1 BD
5- 5 FCOV-B232MRK0 M Door screen [R-426HK] 1 BB
5- 5 FCOV-B236MRK0 M Door screen [R-426HW] 1 BB
5- 6 FBTN-B001MRY0 M Start/Stop button assy 2 AH
5 -7 MSPRTB022MRE0 M Button spring 2 AC
5 -8 XCPSD30P08000 M Screw 1 AB
