24
R-430DK
R-430DW
R-430DQ
R-440DK
R-440DW
Pin No. Signal I/O Description
51-54 COM0-COM3 OUT Terminal not used.
55 BIAS IN Terminal not used.
56 VLC0 IN Terminal not used.
57-58 VLC1-VLC2 IN Terminal not used.
59 VSS0 IN Power source voltage: -5.0V.
The power source voltage to the LSI is input to VSS0 terminal. Connected to VC.
60-83 S0-S23 OUT Terminal not used.
84-97 P97-P82 OUT Data output terminal to LCD driver IC3.
98-99 P81-P80 OUT Terminal not used.
100 P25 OUT Terminal not used.
