38
R-430EK
R-430EW
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
∆
∆
∆
∆
∆
∆
∆
4- 3 PHOK-B018MRF0 M Latch hook 1 AF
4- 4 MLEVPB016MRF0 M Switch lever 1 AD
4- 5 PDUC-B104MRF0 M Magnetron duct 1 AF
4- 6 NFANPB006MRE0 M Fan blade 1 AC
4- 7 PDUC-B088MRF0 M Fan duct 1 AC
4- 8 ------------ M Oven cavity (Not a replaceable part) 1 --
4- 9 PCOVPB085MRP0 M Waveguide cover 1 AD
4- 10 PPACGB014MRF0 M Turntable motor packing 1 AA
4- 11 PDUC-B106MRP0 M AH sensor duct 1 AG
4- 12 PCUSGB033MRP0 M Cushion 1 AA
DOOR PARTS
5- 1 FCOV-B182MRK0 M Door frame assembly [R-430EK] 1 AQ
5- 1 FCOV-B183MRK0 M Door frame assembly [R-430EW] 1 AQ
5- 2 LSTPPB021MRF0 M Latch head 1 AE
5- 3 MSPRTA046WRE0 M Latch spring 1 AB
5- 4 FDORFB062MRT0 M Door panel 1 AW
5- 5 PSHEPB021MRE0 M Sealer film 1 AE
5- 6 GCOVHB042MRF0 M Choke cover 1 AG
5- 7 LSTPPB036MRF0 M Door Glass Stopper 1 AC
5- 8 PGLSPB026MRE0 M Door Glass [R-430EK] 1 AQ
5- 8 PGLSPB027MRE0 M Door Glass [R-430EW] 1 AQ
5- 9 XEPSD30P06XS0 M Screw; 3mm X 6mm 1 AA
MISCELLANEOUS
6- 1 FW-VZB125MRE0 M Stop switch harnnes 1 AF
6- 2 FW-VZB168MRE0 M Main wire harnnes 1 AU
6- 3 QW-QZB016MRE0 M High voltage wire A 1 AC
6- 4 FROLPB025MRK0 M Turntable support 1 AN
6- 5 NTNT-A095WRE0 M Turntable tray 1 AM
6- 6 TCAUAB037MRR0 M Monitor caution label 1 AA
6- 7 TCAUAB038MRR0 M DHHS/Screw caution label 1 AB
6- 8 TINSEB267MRR0 M Operation manual 1 AD
6- 9 TCADUB006MRP0 M RECIPE CARD 1 AC
6- 10 TLABBB007MRE0 M Cavity hole cover 1 AA
6- 11 TLAB-B040MRR0 M Menu Label 1 AD
SCREWS,NUTS AND WASHERS
7- 1 LX-BZA041WRE0 M Special screw 1 AA
7- 2 LX-CZ0052WRE0 M Special screw 3 AA
7- 3 XHTSD40P12RV0 M Screw : 4mm x 12mm 1 AA
7- 4 LX-BZA041WRE0 M Special screw 4 AA
7- 5 XOTSD40P12000 M Screw : 4mm x 12mm 8 AA
7- 6 XCBSD30P08000 M Screw : 3mm x 8mm 2 AA
7- 7 LX-CZA038WRE0 M Special screw 2 AA
7- 8 XHTSD40P08RV0 M Screw : 4mm x 8mm 3 AA
7- 9 LX-CZA070WRE0 M Special screw (Torx tamper proof screw) 2 AB
7- 10 XCPSD30P08000 M Screw : 3mm x 8mm 2 AA
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER
2. REF. NO.
3. PART NO.
4. DESCRIPTION
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts requiring return should be returned as indicated in the Service Policy.
