5
R-430EK
R-430EW
adapter properly grounded and polarized. If the extension cord must be
used, it should be a 3-wire, 15 amp. or higher rated cord. Do not drape
over a countertop or table where it can be pulled on by children or tripped
over accidentally.
CAUTION: DO NOT UNDER ANY CIRCUMSTANCES CUT OR RE-
MOVE THE ROUND GROUNDING PRONG FROM THIS
PLUG.
OVEN DIAGRAM
1. One touch door open button.
Push to open door.
2. Door latches.
The oven will not operate unless the
door is securely closed.
3. Removable turntable support.
4. Removable turntable.
The turntable will rotate clockwise or
counterclockwise.
5. Oven lamp.
It will light when oven is operating or
door is opened.
6. Oven door with see-through window.
7. Ventilation openings. (Rear)
8. Auto-Touch control panel.
9. Time display: Digital display, 99
minutes 99 seconds.
10.Coupling.
11. Wave guide cover.
12. Power supply cord
R-430EK/EW
TOUCH CONTROL PANEL
1
6
5
4
2
10
11
12
9
7
8
3
