R-508FS
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER
2. REF. NO.
3. PART NO.
4. DESCRIPTION
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts requiring return should be returned as indicated in the Service Policy.
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
DOOR PARTS
5 -1 FCOV-B211MRK0 M Door frame assembly 1 AX
5 -2 LSTPPB021MRF0 M Latch head 1 AE
5 -3 MSPRTA046WRE0 M Latch spring 1 AB
5 -4 FDORFB049MRT0 M Door panel 1 AX
5 -5 LSTPPB036MRF0 M Door glass stopper 1 AC
5- 6 PSHEPB016MRE0 M Sealer film 1 AD
5- 7 PGLSPB048MRE0 M Door glass 1 AP
5- 8 HDECAB136MRP0 M Door glass decoration 1 AS
5- 9 GCOVHB039MRF0 M Choke cover 1 AG
5- 10 XEPSD30P06XS0 M Door screw 1 AA
5- 11 PCUSUB058MRP0 M Door cushion 1 AB
MISCELLANEOUS
6- 1 FW-VZB125MRE0 M Stop switch harness 1 AF
6- 2 FW-VZB192MRE0 M Main wire harnes 1 AU
6- 3 TLABBB007MRE0 M Cavity hole cover 1 AA
6- 4 FROLPB025MRK0 M Turntable support 1 AN
6- 5 NTNT-A099WRE0 M Turntable tray 1 AT
6- 6 TCAUAB045MRR0 M Monitor caution label 1 AA
6- 7 TCAUAB038MRR0 M DHHS/Screw caution label 1 AB
6- 8 TINSEB297MRK0 M Operation manual 1 AD
6- 9 QW-QZB016MRE0 M High voltage wire A 1 AC
SCREWS,NUTS AND WASHERS
7- 1 LX-BZA041WRE0 M Special screw 5 AA
7- 2 LX-CZ0052WRE0 M Special screw 2 AA
7- 3 XHTSD40P12RV0 M Screw : 4mm x 12mm 1 AA
7- 4 XOTSD40P12000 M Screw : 4mm x 12mm 8 AA
7- 5 XCBSD30P08000 M Screw : 3mm x 8mm 3 AA
7- 6 LX-CZA038WRE0 M Special screw 2 AA
7- 7 XHTSD40P08RV0 M Screw : 4mm x 8mm 3 AA
7- 8 LX-CZA070WRE0 M Special screw (Torx tamper proof screw) 2 AB
7- 9 XOTSF40P12000 M Special screw 4 AA
To Next Page
