REPLACEMENT PARTS LIST
F
R-662(W)M
or Model:
E11 261201200020 FUSE 1 RT1-20 H 8A 250V
E13+W04 263602100784 LAMP+GUIDE WIND 1
E16 261201003351 POWER CORD ASS'Y 1 BS 1.0M Black
E33 261201300820 THERMOSTAT 160/95 *H 1
E43 251201301370 THERMOSTAT 70/59 *V 1
G02 251200400017 HEATER QUARTZ 2 120V 500W
G06 251501001566 BRKT LIGHT HEATER 1 C17L SGCC T=0.5
G07 251501100004 CONNECTOR QUARTZ HEATER 1 C17L SUS430 T=0.5
G09 261502700300 INSULATOR HEAT *T 1 A21L SGCC T=0.5
L01 261301300701 BRKT INTERLOCK 1 M20L Black
L02 261301100101 LEVER SWITCH 1 M20L Black
L03 261201600180 MICROSWITCH INTERLOCK 2 16A 250V
L04 261201600170 MICROSWITCH MONITOR 1 16A 250V
L05 261202804612 HARNESS MAIN 1 EG820C-PM0E-H1
T01 251200300001 MOTOR TRAY 1 TYJ50-8A7 220-240V
T02 252200100008 COUPLER 1 C23L PPS
T02
252200100008
COUPLER
1
C23L
PPS
T03 262200200024 RING ROTATING ASS'Y 1 M20L SPS
T04 262100500004 TRAY 1 C17L diameterΦ255
W01+W02
+W03
ASS'Y FAN 1 After assembly
W01 261300800501 GUIDE FAN 1 M20L FR
W02
261300900102
FAN
1
C17L FR
W02 261300900102 FAN 1 C17L FR
W03 261200600620 MOTOR FAN 1 220-240V
Z01 261501500300 HOLDER H.V.C 1 A23L SGCC T=0.5
Z05 251301700007 HOLDER POWER CORD 1
Z24 261502641700 CASE OUT 1 M20L SPCC 0.4mm
261900100139 PACKING *T 1 C17L XX 85±7g
261900200117 PACKING *U 1 C17L XX 85±7g
251511701651 RACK 1 C17L SWM-B φ2.5
251202701535 WIRE 1 95mm
261800310904 MANUAL USER
1
261910000229 BIG PLASTIC BAG
1
17/20L
251910100001 SMALL PLASTIC BAG
1
160*250
261862002637 CARTON BOX
1
