38
R-763 -
SCREW, NUT AND WASHER
7-1 XHPSD40P08K00 J Screw 4mm x 8mm 1 AA
7-2 XHTSD40P08RV0 J Screw 4mm x 8mm 5 AA
7-3 XEPSD40P25000 J Screw 4mm x 25mm 2 AA
7-4 XBPWW30P05K00 J Screw 3mm x 5mm 2 AA
7-5 LX-LZA011WRE0 U S S Rivet 2 AB
7-6 XWWSD50-06000 J Washer 4mm x 0.6mm 1 AA
7-7 LX-CZA001URE0 J Screw 4mm x 12mm 17 AA
7-8 XEBSD30P06000 J Screw 3mm x 6mm 4 AA
7-9 XOTSE40P12000 J Screw 4mm x 12mm (W) 4 AA
7-10 XFPSD50P10KS0 J Screw 4mm x 10mm 2 AB
7-11 LX-EZA045WRE0 J TTM cover screw 1 AA
7-12 XHPSD40P06000 J Screw 4mm x 8mm 1 AA
7-13 XOTSD40P12RV0 J Screw 4mm x 8mm 2 AA
6-1 FROLPA002URK0 U Roller stay assembly 1 AM
6-2 NTNT-A051WRE0 U Turntable 1 AN
6-3 TINS-A219URR0 U Instruction book 1 AM
* 6-5 QW-QZA210WRE1 U H.V. wire B 1 AD
6-6 FW-VZA079URE1 U Main wire harness 1 AU
6-7 TCAUHA006URR0 U Combined caution label 1 AE
6-9 FAMI-A072WRK2 U High rack 1 AY
6-10 FAMI-A073WRK3 U Low rack 1 AX
6-11 FW-VZA061URE0 U Stop switch harness 1 AE
6-13 LHLDKA008WRF0 U P. clip 1AA
DOOR PARTS
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
∆
∆
∆
∆
MISCELLANEOUS
*
5-1 DDORFA752WRK0 U Door panel assembly 1 AY
5-2 GCOVHA365WRF2 U Choke cover 1 AM
5-3 GWAKPS021URT0 U Door frame 1 AT
5-4 PGLSPA026URR0 U Door glass 1 AX
5-5 LSTPPA017URF0 U Latch head 1 AG
5-6 MSPRTA197WRE2 U Latch spring 1 AC
5-7 PSHEPA424WRE2 U Door film 1 AG
5-8 FDORFA287WRT0 U Door panel sub assembly 1 AW
5-9 XEBSD30P06000 U Screw 3mm x 6mm 4 AA
5-10 JHNDPK002URF0 U Door handle(BLK) 1 AD
∆
∆
PARTS LIST
REF. NO. PART NO. § DESCRIPTION Q’TY CODE
Note: The parts marked “*” are used in voltage more than 250V. The parts marked "∆" may cause undue microwave exposure
“§” MARK: SPARE PARTS-DELIVERY SECTION
To Next Page
