38
*
*
∆
∆
∆
∆
∆
Note: The parts marked "∆" may cause undue microwave exposure. / The parts marked "*" are used in
voltage more than 250V. / "§" Mark: Spare parts delivery section
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
∆
PARTS LIST
∆
OVEN PARTS
4- 1 DOVN-A016URK0 U Oven cavity 1 BK
4- 2 LBNDKA107WRP1 U Capacitor holder 1 AD
4- 3 FDUC-A003URY0 U Air duct assembly 1 AL
4- 4 LANGQA005URP0 U Air separate angle B 1 AC
4- 5 PDUC-A636WRP0 U Air guide duct 1 AN
4- 6 PFILWA001URP0 U Lamp filter 1 AB
4- 7 PHOK-A078WRF5 U Latch hook 1 AH
4- 8 LANGQA014URP0 U Turntable motor angle 1 AE
4- 9 PSKR-A308WRF0 U Rear barrier 1 AH
4-10 FANGTA003URY0 U Turntable motor shaft assembly 1 AK
4-11 PPACGA108WRE0 U Packing 1 AC
4-12 NFANJA001URE0 U Fan blade 1 AF
4-13 PDUC-A637WRF2 U Fan duct 1 AL
4-14 PDUC-A008URP0 U Exhaust duct 1 AK
4-15 GCOVHA001URP0 U Bottom heater cover 1 AL
4-16 LANGFA155WRP7 U Chassis support 1 AF
4-17 PPACGA001URE0 U Heater packing 1 AD
4-18 LANGQA008URP0 U Grill heater angle 2 AD
4-19 MLEVPA001URF3 U Open lever 1 AE
4-20 PSPAGA001WRE0 U Vibration proof cushion 1 AA
4-22 PCOVQA002URP0 U Heater cover 2 AD
4-23 PCOVPA308WRE1 U Waveguide cover 1 AE
4-24 PCUSGA372WRP0 U HVT Cushion 1 AB
4-25 PCUSGA317WRP0 U Absorb cushion A 1 AA
4-26 PCUSUA459WRP0 U Waveguide Cushion 1 AC
4-27 PDUC-A633WRF1 U Air intake duct 1 AK
DOOR PARTS
5- 1 DDORFA766WRK0 U Door panel assembly 1 BE
5- 2 GWAKPW027URR0 U Door frame [R-772(W)M] 1 AT
5- 2 GWAKPG008URR0 U Door frame [R-772(G)M] 1 AT
5- 3 LSTPPA147WRF1 U Latch head 1 AE
5- 4 LSTPPA003URF0 U Glass stopper 1 AB
5- 5 MSPRTA141WRE0 U Latch spring 1 AA
5- 6 PGLSPA020URR0 U Front door glass 1 AX
5- 7 XEBSD30P06000 U Screw : 3mm x 6mm 6 AA
5- 8 GCOVHA365WRF2 U Choke cover 1 AM
MISCELLANEOUS
6- 1 TCAUHA001WRR1 U Caution label 1 AC
6- 2 FAMI-A095WRK1 U Rack 1 AR
6- 3 LHLDKA008WRF0 U P-clip 1 AA
6- 4 CTNT-A002URK0 U Turntable tray 1 AY
6- 5 FW-VZA031URE0 U Stop switch harness 1 AE
6- 6 QW-QZA014URE0 U High voltage wire A 1 AB
6- 7 QW-QZA210WRE1 U High voltage wire B 1 AD
6- 8 FW-VZA070URE1 U Main harness 1 AX
6-10 TINS-A175URR0 U Operation manual 1 AS
6-11 TINS-A176URR0 U Quick start guide 1 AM
SCREWS,NUTS AND WASHERS
7- 1 XHPSD40P08K00 U Screw: 4mm x 8mm 1 AA
7- 2 XOTSD40P10000 U Screw: 4mm x 10mm 3 AA
7- 3 XWWSD50-06000 U Washer: 5mm x 0.6mm 1 AA
7- 4 XOTSE40P10000 U Screw: 4mm x 12mm [R-772(W)M] 4 AA
7- 4 XOTSF40P10000 U Screw: 4mm x 12mm [R-772(G)M] 4 AA
7- 5 XNEUW40-32000 J M4 Stainless nut 4 AA
7- 6 XHTSD40P08RV0 J Screw: 4mm x 8mm 6 AA
7- 7 LX-EZA045WRE0 J TTM cover screw 1 AA
7- 8 XEBSD30P06000 J Screw: 3mm x 6mm 2 AA
7- 9 XFPSD40P08000 U Screw: 4mm x 8mm 1 AA
7-10 XHPSD40P08000 U Screw: 4mm x 8mm 1 AA
7-11 XFPSD50P10KS0 U Screw: 5mm x 10mm 2 AC
7-12 LX-CZA001URE0 J Screw: 4mm x 12mm 21 AA
7-13 XVPSD30P05K00 J Screw: 3mm x 5mm 2 AA
7-14 XEPSD40P25000 J Screw: 4mm x 25mm 2 AA
7-15 XCTWW40P06000 U Screw: 4mm x 6mm 3 AA
To Next Page
