Sharp R-7N76(B)M User Manual

R-7N76(W)M
R-7N76(B)M
42
∆
∆
∆
Note: The parts marked "∆" may cause undue microwave exposure. / The parts marked "*" are used in
voltage more than 250V. / "§" Mark: Spare parts delivery section
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
D21-30 VHD1SS270A/-1 J Diode (1SS270ATA) 10 AA
D73-78 VHD1SS270A/-1 J Diode (1SS270ATA) 6 AA
IC1 RH-IZA627DRE0 J LSI 1 AS
IC2 RH-IZA521DRE0 J IC (X24C02P) 1 AL
IC3 RH-IZA495DRE0 J IC 1 AL
Q1 VS2SB910MR/-4 J Transistor (2SB910M) 1 AE
Q4 VSDTA143ES/1B J Transistor (DTA143ES) 1 AB
Q10 VSDTA143ES/1B J Transistor (DTA143ES) 1 AB
Q20 VSDTA143ES/1B J Transistor (DTA143ES) 1 AB
Q21 VSDTD143ES/-3 J Transistor (DTD143ES) 1 AC
Q22 VSDTB143ES/-3 J Transistor (DTB143ES) 1 AC
Q23-27 VSDTA143ES/1B J Transistor (DTA143ES) 5 AB
Q40 VSDTA143ES/1B J Transistor (DTA143ES) 1 AB
R1 VRD-B12HF432J J Resistor 4.3k ohm 1/2W 1 AH
R2 VRD-B12EF242J J Resistor 2.4k ohm 1/4W 1 AA
R3 VRS-B13AA681J J Resistor 680 ohm 1W 1 AA
R4 VRD-B12HF511J J Resistor 510 ohm 1/2W 1 AB
R5 VRD-B12EF153J J Resistor 15k ohm 1/4W 1 AA
R10 VRD-B12EF153J J Resistor 15k ohm 1/4W 1 AA
R21-24 VRD-B12EF470J J Resistor 47 ohm 1/4W 4 AB
R30 VRD-B12EF152J J Resistor 1.5k ohm 1/4W 1 AA
R31 VRD-B12EF512J J Resistor 5.1k ohm 1/4W 1 AA
R40 VRD-B12EF332J J Resistor 3.3k ohm 1/4W 1 AA
R50 VRD-B12EF151J J Resistor 150 ohm 1/4W 1 AA
R51-52 VRD-B12EF153J J Resistor 15k ohm 1/4W 2 AA
R53 VRD-B12EF272J J Resistor 2.7k ohm 1/4W 1 AA
R60 VRN-B12EK913F J Resistor 91k ohm 1/4W 1 AA
R61 VRN-B12EK101F J Resistor 100 ohm 1/4W 1 AA
R62 VRN-B12EK272F J Resistor 2.7k ohm 1/4W 1 AA
R70-73 VRD-B12EF153J J Resistor 15k ohm 1/4W 4 AA
R80 VRD-B12EF152J J Resistor 1.5k ohm 1/4W 1 AA
R81 VRD-B12EF512J J Resistor 5.1k ohm 1/4W 1 AA
R90 VRS-B13AA331J J Resistor 330 ohm 1W 1 AA
RY1 RRLY-A076DRE0 J Relay (OMIF-S-124LM) 1 AK
RY2 RRLY-A081DRE0 J Relay (VRB24) 1 AL
RY3-4 RRLY-A076DRE0 J Relay (OMIF-S-124LM) 2 AK
OVEN PARTS
4- 1 DOVN-A418WRK0 U Oven cavity 1 BP
4- 2 LBNDKA089WRP0 U Capacitor holder 1 AE
4- 3 FDUC-A280WRK0 U Exhaust duct assembly 1 AR
4- 4 PSLDHA112WRP1 U Heater cover R 1 AL
4- 5 LANGQA308WRP0 U Convection motor mounting plate 1 AE
4- 6 NFANMA011WRP0 J Convection fan 1 AD
4- 7 FFANMA014WRY0 U Cooling fan assembly 1 AF
4- 8 FDUC-A261WRK0 U Convection duct assembly 1 AP
4- 9 PFPF-A171WRE1 U Rear heat intercept 1 AK
4-10 PPIPFA013WRE0 U Pipe 1 AE
4-11 PSKR-A268WRP0 U Conv. air angle A 1 AD
4-12 PSKR-A269WRP0 U Conv. air angle B 1 AD
4-13 FSLDHA017WRK2 U Rear heat cover 1 AP
RY5-7 RRLY-A080DRE0 J Relay (OJ-SH-124LM) 2 AG
SP40 RALM-A014DRE0 J Buzzer (PKM22EPT) 1 AG
VRS1 RH-VZA032DRE0 J Varistor (10G471K) 1 AE
ZD1 VHEHZ6A3///-1 J Zener diode (HZ6A3) 1 AA
ZD2 VHEHZ161///-1 J Zener diode (HZ16-1) 1 AA
ZD3 VHEHZ5C2///-1 J Zener diode (HZ5C2) 1 AA
ZD4 VHEHZ4A2///-1 J Zener diode (HZ4A2) 1 AA
3- 2 DUNTKA654WRK0 J Key unit assembly [R-7N76(B)M] 1 BA
3- 2 DUNTKA655WRK0 J Key unit assembly [R-7N76(W)M] 1 BA
3- 2-1 FUNTKA666WRE0 J Key unit [R-7N76(B)M] 1 AZ
3- 2-1 FUNTKA667WRE0 J Key unit [R-7N76(W)M] 1 AZ
3- 3 HPNLCB147WRF0 U Control panel [R-7N76(B)M] 1 AM
3- 3 HPNLCB148WRF0 U Control panel [R-7N76(W)M] 1 AM
3- 4 GMADIA082WRF0 U Display window 1 AD
3- 5 JBTN-A871WRF0 U Open button [R-7N76(B)M] 1 AD
3- 5 JBTN-A872WRF0 U Open button [R-7N76(W)M] 1 AD
3- 6 MSPRCA045WRE0 U Open button spring 1 AA
3- 7 XEPSD30P10XS0 J Screw 4 AA
3- 8 XCPSD30P08X00 J Screw 1 AA
