41
R-820BK
R-820BW
*
*
*
*
∆
*
∆
*
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 QSW-MA110WRE0 Secondary interlock switch / door sensing switch 2 AH
1- 1 QSW-MA131WRE0
Secondary interlock switch / door sensing switch (Interchangeable)
2AG
1- 2 FFS-BA021WRK0 Monitor fuse and monitor switch assembly 1 AL
1- 3 RMOTDA231WRE0 Turntable motor 1 AR
1- 3 RMOTDA188WRE0 Turntable motor (Interchangeable) 1 AS
1- 4 FH-DZA025WRK0 High voltage rectifier assembly 1 AN
1- 5 RC-QZA173WRE0 High voltage capacitor 1 AX
1- 5 RC-QZA211WRE0 High voltage capacitor (Interchangeable) 1 AV
1- 6 RMOTEA370WRE0 Fan motor 1 AX
1- 7 QFSHDA009WRE0 Fuse holder 1 AG
1- 7 QFSHDA010WRE0 Fuse holder (Interchangeable) 1 AD
1- 8 FACCDA074WRE0 Power supply cord 1 AW
1- 9 FH-HZA063WRE0 Thremistor 1 AP
1-10 RMOTEA372WRE0 Convection motor 1 AX
1-11 QTANNA017WRW0 Short terminal 1 AD
1-12 RHET-A208WRE0 Grill heater (Top heater) 2 AU
1-13 RHET-A209WRE0 Bottom heater 1 BA
1-14 RLMPTA030WRE0 Oven lamp 1 AE
1-15 QSOCLA021WRE0 Oven lamp socket 1 AG
1-16 RTHM-A048WRE0 Thermal cut-out 170 deg. 1 AH
1-17 RTHM-A078WRE0 Thermal cut-out 125 deg. 1 AK
1-18 RTRN-A568WRE0 Power transformer 1 BP
1-19 RV-MZA222WRE0 Magnetron 1 BN
1-19 RV-MZA267WRE0 Magnetron (Interchangeable) 1 BL
CABINET PARTS
2- 1 GCABDA097WRW0 Back plate 1 AW
2- 2 GCABUA631WRP0 Outer case cabinet [R-820BK] 1 BB
2- 2 GCABUA649WRP0 Outer case cabinet [R-820BW] 1 AZ
2- 3 GDAI-A305WRW0 Base plate 1 AX
2- 4 GLEGPA074WRE0 Leg 1 AC
CONTROL PANEL PARTS
3- 1 CPWBFA791WRK0 Power unit 1 BF
3- 1A QCNCMA234DRE0 3-pin connector (CN-A) 1 AC
3- 1B QCNCMA275DRE0 2-pin connector (CN-B) 1 AB
3- 1C FW-VZA238DRE0 9pin wire harness (WH-1, WH-2) 2 AK
3- 1D QCNCMA410DRE0 2-pin connector (CN-D) 1 AB
C1 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C2 VCEAB31HW477M Capacitor 470 uF 50V 1 AE
C3 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C4-5 VCEAB31VW106M Capacitor 10 uF 35V 2 AA
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D5-7 VHD1SS270A/-1 Diode (1SS270A) 3 AA
D8-12 VHD1SS270A/-1 Diode (1SS270A) 5 AA
Q2 VS2SB1238//-3 Transistor (2SB1238) 1 AA
Q3 VSDTD143ES/-3 Transistor (DTD143ES) 1 AC
R2-3 VRD-B12HF511J Resistor 510 ohm 1/2W 2 AB
R4 VRD-B12EF270J Resistor 27 ohm 1/4W 1 AB
R5 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R6 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
RY1 RRLY-A080DRE0 Relay (OJ-SH-124LM) 1 AG
RY2 RRLY-A081DRE0 Relay (VRB24) 1 AL
RY3-4 RRLY-A076DRE0 Relay (OMIF-S-124LM) 2 AK
RY5 RRLY-A080DRE0 Relay (OJ-SH-124LM) 1 AG
RY6 RRLY-A076DRE0 Relay (OMIF-S-124LM) 1 AK
SP1 RALM-A014DRE0 Buzzer (PKM22EPT-THAI) 1 AG
T1 RTRNPA124DRE0 Transformer 1 AQ
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
3- 2 DPWBFB794WRK0 CPU unit 1 BC
3- 3 DPNLCB494WRK0 Control panel frame with key unit [R-820BK] 1 BA
3- 3 DPNLCB496WRK0 Control panel frame with key unit [R-820BW] 1 BB
3- 3-1 JBTN-B086WRF0 Open button [R-820BW] 1 AF
3- 3-1 JBTN-B092WRF0 Open button [R-820BK] 1 AF
3- 3-2 MSPRCA050WRE0 Open button spring 1 AB
3- 3-3 FUNTKA869WRE0 Key unit [R-820BK] 1 AX
3- 3-3 FUNTKA871WRE0 Key unit [R-820BW] 1 AX
