Sharp R-820BK - Oven Parts; Door Parts; Miscellaneous

42
R-820BK
R-820BW
∆
∆
∆
∆
∆
∆
*
REF. NO. PART NO. DESCRIPTION Q'TY CODE
3- 4 LHLD-A185WRF0 LCD holder 1 AL
3- 5 PSHEPA626WRE0 LED sheet 1 AF
3- 6 TCAUAA076WRR0 User caution label 1 AB
3- 7 XEPSD30P08XS0 Screw; 3mm x 8mm 4 AA
OVEN PARTS
4- 1 ************* Oven cavity (Not a replaceable part) 1--
4- 2 PHOK-A106WRF0 Latch hook 1 AL
4- 3 FDUC-A337WRK0 Air duct assembly 1 BH
4- 4 PCOVPA340WRW0 Sub back plate 1 AQ
4- 5 LANGQA478WRP0 Turntable motor angle 1 AP
4- 6 MSPRTA186WRE0 Plate spring 1 AE
4- 7 NCPL-A051WRE0 Turntable motor shaft 1 AN
4- 8 PSPA-A109WRE0 Spacer 1 AB
4- 9 LBNDKA136WRP0 HV capacitor holder 1 AQ
4-10 NFANJA041WRE0 Fan blade 1 AF
4-11 PDUC-A697WRF0 Fan duct 1 AM
4-12 GCOVHA388WRW0 Bottom heater cover 1 AF
4-13 GLEGPA071WRF0 Leg 1 AG
4-14 LANGFA185WRP0 Chassis support 1 AM
4-15 LANGQA489WRP0 Thermistor angle 1 AW
4-16 LFLG-A025WRE0 Bearing 1 AM
4-17 MLEVPA226WRF0 Switch lever 1 AF
4-18 MSPR-A004WRE0 Heat seal spring 2 AF
4-19 PCOV-A011WRP0 Bottom heater angle 2 AM
4-20 PCOVPA339WRE0 Waveguide cover 1 AF
4-21 PCUSGA385WRP0 Cushion 2 AH
4-22 PCUSUA190WRP0 Cushion 1 AC
4-23 PCUSUA191WRP0 Cushion 1 AC
4-24 PDUC-A691WRF0 Air intake duct 1 AG
4-25 PDUC-A692WRP0 Exhaust duct 1 AS
4-26 PDUC-A696WRP0 Air guide 1 AT
4-27 PGLSPA518WRE0 Light glass 1 AZ
4-28 PPACGA041WRE0 Cushion 1 AE
4-29 PREFHA061WRW0 Reflector 1 BE
4-30 PSHEPA487WRE0 Heater film 1 AA
4-31 PSKR-A331WRP0 Air separate angle 1 AY
4-32 MSPRCA113WRE0 H-spring 2 AC
4-33 PCUSGA420WRP0 Cushion 1 AE
4-34 NFANMA047WRP0 Convection fan 1 AX
4-35 NFANMA048WRP0 Cooling fan 1 AX
4-36 PCUSUA499WRP0 Cushion 1 AC
4-37 PDUC-A707WRW0 Convection duct 1 AR
4-38 PFPF-A210WRE0 Thermal insulation 1 AM
4-39 PPIPFA030WRE0 Pipe 1 AK
4-40 PSKR-A339WRP0 Convection air angle 2 AX
4-41 PSKR-A345WRW0 Convection motor angle A 1 AU
4-42 PSKR-A346WRW0 Convection motor angle B 1 AR
4-43 PSLDHA140WRW0 Convection thermal cover 1 AQ
DOOR PARTS
5- 1 DDORFA857WRK0 Door panel assembly 1 BB
5- 2 GWAKPA570WRR0 Door frame [R-820BK] 1 AY
5- 2 GWAKPA572WRR0 Door frame [R-820BW] 1 AX
5- 3 LSTPPA176WRF0 Latch head 1 AN
5- 4 LSTPPA177WRF0 Glass stopper 1 AF
5- 5 MSPRTA187WRE0 Latch spring 1 AC
5- 6 PGLSPA513WRE0 Front door glass [R-820BK] 1 AV
5- 6 PGLSPA514WRE0 Front door glass [R-820BW] 1 AW
5- 7 XCPSD40P06000 Screw : 4mm x 6mm 2 AA
5- 8 XCPSD40P08000 Screw : 4mm x 8mm 4 AA
5- 9 GCOVHA387WRF0 Choke cover 1 AS
MISCELLANEOUS
6- 1 FAMI-A104WRM0 Rack 1 AQ
6- 2 TCAUAA145WRR0 Earth caution 1 AG
6- 3 FSRAHA062WRY0 Turntable support 1 BC
6- 4 NTNT-A097WRE0 Turntable 1 BB
6- 5 TCAUAA200WRR0 Monitor caution 1 AB
6- 6 TINSEA752WRR0 Instruction book 1 AS
6- 7 FW-VZB045WRE0 Switch harness 1 AG
6- 8 FW-VZB673WRE0 Main wire harness 1 AY
6- 9 QW-QZA213WRE0 High voltage wire B 1 AF
