Sharp R-84ST Service Manual

45
R-84ST -
∆
∆
5- 1 DDORFA766WRK0 U Door panel assembly 1 BE
5- 2 GWAKPR005URF0 U Door frame 1 AT
5- 3 LSTPPA016URF0 U Latch head 1 AA
5- 4 LSTPPA003URF0 U Glass stopper 1 AB
5- 5 MSPRTA002URE0 U Latch spring 1 AA
5- 6 PGLSPA479WRE1 U Front door glass 1 AX
5- 7 XEPSD30P06XS0 U Screw : 3mm x 6mm 6 AA
5- 8 GCOVHA365WRF3 U Choke cover 1 AM
6- 1 FAMI-A072WRK2 U High rack 1 AT
6- 2 FAMI-A095WRK1 U Low rack 1 AR
6- 3 LHLDKA008WRF0 U P-clip 1 AA
6- 4 CTNT-A002URK0 U Turntable tray 1 AY
6- 5 FW-VZA093URE0 U Stop switch harness 1 AX
6- 7 QW-QZA210WRE1 U High voltage wire B 1 AD
6- 8 FW-VZA071URE1 U Main harness 1 AY
6- 9 TINS-A272URR0 U Quick start guide 1 AC
6-10 TINS-A270URR0 U Operation manual 1 AM
6-11 TCADCA009URR0 U Cook book 1 AP
6-12 TLABMA119URR0 U Menu label 1 AE
6-13 TCAUHA006URR0 U Caution label 1 AE
7- 1 XHPSD40P08K00 U Screw: 4mm x 8mm 1 AA
7- 2 XOTSD40P10000 J Screw: 4mm x 10mm 3 AA
7- 3 XWWSD50-06000 J Washer: 5mm x 0.6mm 1 AA
7- 4 XOTSC40P12000 J Screw: 4mm x 12mm 4 AA
7- 5 LX-NZ0061WRE0 J M4 Flange nut 4 AA
7- 6 XHTSD40P08RV0 J Screw: 4mm x 8mm 6 AA
7- 7 XCBWW30P06000 J Screw: 3mm x 6mm 2 AB
7- 8 XBPSD40P05000 U Screw: 4mm x 5mm 2 AA
7- 9 XNEUW40-32000 J Nut: 4mm x 3.2mm 1 AA
7-10 XHPSD40P08000 J Screw: 4mm x 8mm 1 AA
7-11 XRESE40-06000 U Ring 1 AA
7-12 XWHUW40-08000 U Washer: 4mm x 0.8mm 1 AA
7-13 XWSUW40-10000 U Washer: 4mm x 1.0mm 1 AA
7-14 XEPSD40P25000 J Screw: 4mm x 25mm 2 AA
7-15 XCTWW40P06000 U Screw: 4mm x 6mm 10 AA
7-16 LX-EZA045WRE0 J TTM cover screw 1 AA
7-17 XCPSD30P06000 J Screw: 3mm x 6mm 2 AA
7-18 XFPSD40P08000 U Screw: 4mm x 8mm 1 AA
7-19 XFPSD50P10KS0 U Screw: 5mm x 10mm 2 AB
7-20 LX-CZA001URE0 J Screw: 4mm x 12mm 24 AA
7-21 XBPWW30P05K00 U Screw: 3mm x 5mm 2 AA
7-22 XWHUW50-08000 J Washer: 5mm x 0.8mm 1 AA
7-23 XOTSD40P12000 J Screw: 4mm x 12mm 2 AA
Note: The parts marked "∆" may cause undue microwave exposure. / The parts marked "*" are used in
voltage more than 250V. / "§" Mark: Spare parts delivery section
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
PARTS LIST
DOOR PARTS
MISCELLANEOUS
SCREWS,NUTS AND WASHERS
∆
*
