Sharp R-885 Service Manual

R-875/885 - 47
Note: The parts marked "∆" may cause undue microwave exposure. / The parts marked "*" are used in
voltage more than 250V. / "§" Mark: Spare parts delivery section
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
*
*
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER 3. PART NO.
2. REF. NO. 4. DESCRIPTION
PARTS LIST
5- 7 JHNDPA012URT0 U Door handle A [R-885(AL)] 1 AK
5- 8 JHNDPB002URF0 U Door handle B [R-875(B)] 1 AE
5- 8 JHNDPK006URF0 U Door handle B [R-875(K)] 1 AE
5- 8 JHNDPW003URF0 U Door handle B [R-875(W)] 1 AR
5- 8 JHNDPA013URT0 U Door handle B [R-885(AL)] 1 AR
5- 9 XETSD40P30000 U Screw: 4mm x 30mm 2 AA
5-10 XEBSD30P08000 U Screw: 3mm x 8mm 3 AA
5-11 XEBSD30P06000 U Screw: 3mm x 6mm 4 AA
5-12 GCOVHA365WRF3 U Choke cover 1 AM
MISCELLANEOUS
6- 1 FAMI-A072WRK2 U High rack 1 AT
6- 2 FAMI-A095WRK1 U Low rack 1 AR
6- 3 LHLDKA008WRF1 U P-clip 1 AA
6- 4 CTNT-A005URK0 U Turntable tray 1 AY
6- 5 FW-VZA061URE1 U Stop switch harness 1 AE
6- 7 QW-QZA210WRE1 U High voltage wire B 1 AD
6- 8 FW-VZA098URE1 U Main harness 1 AX
6- 9 TINS-A292URR0 U Quick start guide 1 AD
6-10 TINS-A291URR0 U Operation manual 1 AW
6-11 TLABMA205URR0 U Menu label [R-875(W)][R-885(AL)] 1 AD
6-11 TLABMA207URR0 U Menu label [[R-875(B)]R-875(K)] 1 AD
SCREWS,NUTS AND WASHERS
7- 1 XHPSD40P08K00 U Screw: 4mm x 8mm 1 AA
7- 2 LX-NZ0061WRE0 J M4 Flange nut 4 AA
7- 3 XWWSD50-06000 J Washer: 5mm x 0.6mm 1 AA
7- 4 XOTSE40P10000 U Screw: 4mm x 10mm [R-875(W)][R-885(AL)] 4 AA
7- 4 XOTSF40P10000 U Screw: 4mm x 10mm [R-875(B)][R-875(K)] 4 AA
7- 5 XHPSD40P06000 J Screw: 4mm x 6mm 3 AA
7- 6 XHTSD40P08RV0 J Screw: 4mm x 8mm 6 AA
7- 7 XOTWW40P06000 J Screw: 4mm x 6mm 10 AA
7- 8 XBTSD40P05000 U Screw: 4mm x 5mm 2 AA
7- 9 XNEUW40-32000 J Nut: 4mm x 3.2mm 1 AA
7-10 XOTSD40P12RV0 J Screw: 4mm x 12mm 2 AA
7-11 XRESE40-06000 U Ring 1 AA
7-12 XWHUW40-08000 U Washer: 4mm x 0.8mm 1 AA
7-13 XWSUW40-10000 U Washer: 4mm x 1.0mm 1 AA
7-14 XEPSD40P25000 J Screw: 4mm x 25mm 2 AA
7-15 XBPWW30P05K00 U Screw: 3mm x 5mm 2 AA
7-16 XWHUW50-08000 J Washer: 5mm x 0.8mm 1 AA
7-17 XEBSD30P06000 J Screw: 3mm x 6mm 3 AA
7-18 LX-CZA001URE0 U Special screw 24 AA
7-19 XFPSD50P10KS0 U Screw: 5mm x 10mm 2 AB
7-20 LX-EZA045WRE0 J TTM cover screw 1 AA
