Sharp R-930CS Service Manual

43
R-930CS
REF. NO. PART NO. DESCRIPTION Q'TY CODE
4-22 NCPL-A021WRF0 Turntable coupling 1 AE
4-23 PCOVPA301WRE0 Waveguide cover 1 AE
4-24 PCUSUA197WRP0 Cushion 2 AD
4-25 PGLSPA455WRE0 Light glass 1 AD
4-26 PFPF-A139WRE0 Thermal protection sheet (Right) 1 AF
4-27 PREFHA053WRW0 Thermal protection plate (Right) 1 AP
4-28 PSKR-A153WRW0 Air guide (Bottom) 1 AK
4-29 PSKR-A323WRW0 Air guide (Right) 1 AF
4-30 LANGQA407WRW0 Convection motor mounting plate 1 AG
4-31 NPLYBA021WRF0 Pulley (M) 1 AC
4-32 NFANJA020WRE0 Fan blade 1 AE
4-33 PDUC-A270WRF0 Cooling fan duct 1 AL
4-34 LANGFA089WRW0 Chassis support 1 AE
4-35 MHNG-A165WRM0 Oven hinge (Upper) 1 AE
4-36 NBLTKA005WRE0 Convection fan belt 1 AF
4-37 PFPF-A064WRE0 Thermal protection sheet 1 AF
4-38 PCUSUA196WRP0 Cushion 2 AD
4-39 PCUSUA425WRP0 Damper duct cushion 1 AG
4-40 PCUSGA353WRP0 Cushion 1 AH
4-41 PSKR-A171WRW0 Magnetron air guide 1 AE
DOOR PARTS
5 CDORFA844WRK0 Door panel assembly complete 1 BS
5- 1 DDORFA820WRY0 Door panel 1 BD
5- 2 PGLSPA534WRE0 Door glass 1 AZ
5- 3 GCOVHA155WRF0 Choke cover 1 AP
5- 4 GWAKPA665WRF0 Door frame 1 AX
5- 5 GCOVAA273WRP0 Door decoration 1 BA
5- 6 LANGKA851WRT0 Latch angle 1 AF
5- 7 LSTPPA169WRF0 Latch head 1 AH
5- 8 MSPRTA192WRE0 Latch head spring 1 AC
5- 9 LANGKA918WRW0 Thermal plate U 1 AH
5-10 LANGKA919WRW0 Thermal plate R 1 AF
5-11 XCPSD40P08000 Screw; 4mm x 8mm 6 AA
5-12 XEBSD30P08000 Screw; 3mm x 8mm 12 AA
5-13 PCUSGA537WRPZ Cushion 1 AD
MISCELLANEOUS
6- 1 FAMI-A088WRM0 Low rack (Broiling trivet) 1 AW
6- 2 FAMI-A087WRM0 High rack (Baking rack) 1 AW
6- 3 TCADCA522WRR0 Cook book 1 BA
6- 4 FW-VZB342WRE0 Thermistor harness 1 AN
6- 5 FW-VZB668WRE0 Main wire harness 1 AZ
6- 6 QW-QZA198WRE0 High voltage wire B 1 AN
6 -7 QW-VZA108WRE0 Grounding wire (Cooling fan motor) 1 AF
6- 8 TCAUAA240WRR0 Screw caution label 1 AC
6- 9 TCAUAA200WRR0 Monitor caution label 1 AB
6-10 TCAUAA209WRR0 DHHS caution label 1 AD
6-11 TINSEA815WRR0 Operation manual 1 AG
SCREWS NUTS AND WASHERS
7- 1 XOTWW40P10000 Screw; 4mm x 10mm 14 AA
7- 2 XOTSE40P12000 Screw; 4mm x 12mm 4 AA
7- 3 XCTWW40P08000 Screw; 4mm x 8mm 2 AA
7- 4 XHTSD40P08RV0 Screw; 4mm x 8mm 1 AA
7- 5 LX-CZ0052WRE0 Special screw 2 AA
7- 6 XWVSD60-07000 Washer; 6mm x 0.7 mm 1 AA
7- 7 LX-WZA004WRE0 Washer 1 AA
7- 8 LX-CZA074WRE0 Special screw 6 AC
7- 9 XBPSD30P14K00 Screw; 3mm x 14mm 1 AA
7-10 XBPSD40P25000 Screw; 4mm x 25mm 2 AA
7-11 XBTWW40P06000 Screw; 4mm x 6mm 7 AA
7-12 XCTSD40P08000 Screw; 4mm x 8mm 7 AA
7-13 XCPSD40P10000 Screw; 4mm x 10mm 1 AA
7-14 XBPSD40P06KS0 Screw; 4mm x 6mm 2 AA
7-15 LX-WZA022WRE0 Washer 1 AB
7-16 XCPSD40P08000 Screw; 4mm x 8mm 6 AA
7-17 XCPSD30P06000 Screw; 3mm x 6mm 3 AA
7-18 LX-CZA070WRE0 Special screw (Torx tamper proof screw) 2 AC
7-19 XHPSD40P08K00 Screw; 4mm x 8mm 2 AC
7-20 XHTSD40R12RV0 Screw; 4mm x 12mm 1 AA
7-21 XCBWW30P06000 Screw; 3mm x 6mm 4 AA
7-22 XFPSD40P08000 Screw; 4mm x 8mm 6 AA
7-23 XFPSD60P14JS0 Screw; 6mm x 14mm 2 AB
∆
∆
∆
∆
∆
∆
*
