R-953/963M - 41
Figure S-5(a). Key Unit Circuit (R-953(IN)M/(W)M)
IC1-6(P73)
IC1-7(P72)
IC1-8(P71)
IC1-9(P70)
VC
GND
IC1-77(AN4)
IC1-39(P17)
R67 15k R66 15k
R75 100k
R68 15k
: IF NOT SPECIFIED 0.01µF/25V
: IF NOT SPECIFIED 1/10W ± 5%
5597-12CPB
R69 15k
R70 15k
R71 15k
R74 100k R73 100k R72 100k
C63 330pF/50v C62 330pF/50v C61 330pF/50v C60 330pF/50v
R65 15k R64 15k R63 15k R62 15k R61 15k R60 15k
IC1-40(P16) IC1-41(P15) IC1-42(P14) IC1-43(P13) IC1-44(P12) IC1-45(P11) IC1-46(P10)
IC1-22(INT1)
IC1-18(P47)
G12 G11 G10 G 9
G 8
ROAST
POULTRY
ROAST
PORK
MINCED
MEAT
MORE
STEAK/
CHOPS
KITCHEN
TIMER
Kg / Lb
10 sec. 1 min. 10 min.
GRILL
CHICKEN
PORTIONS
AUTO
COOK
MICRO.
POWER
CONV.
(˚C)
LESS UP DOWN
DUAL
CONV./
GRILL
ROAST
BEEF/
LAMB
AUTO
START
AUTO
MINUTE
CLOCK
START
G 7
G 6 G 5 G 4 G 3 G 2 G 1
STOP
CLEAR
KEY UNIT CIRCUIT (R-953(SL)M
