Note: The parts marked "∆" may cause undue microwave exposure. / The parts marked "*" are used in
voltage more than 250V. / "§" Mark: Spare parts delivery section
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
∆
∆
3- 7 HDECQS001URT0 U Panel sash [R-963(W)] 1 AR
3- 8 HPNLCS016URT0 U Control panel frame [R-963(IN)] 1 AU
3- 8 HPNLCW052URF0 U Control panel frame [R-963(W)] 1 AU
3- 9 XEPSD30P10XS0 U Screw : 3mm x 10mm 3 AA
OVEN PARTS
4- 1 PSKR-A011URP0 U Magnetron guide H 1 AN
4- 2 PCUSUA026URP0 U Cushion B 1 AB
4- 3 PSKR-A009URP0 U Magnetron guide V 1 AG
4- 4 DOVN-A018URK0 U Oven cavity 1 BL
4- 5 MCAMPA001URF0 U Damper cam 1 AD
4- 6 LANGTA009URP0 U Damper angle 1 AC
4- 7 PFTA-A001URF0 U Damper 1 AD
4- 8 PCUSUA025URP0 U Cushion A 1 AC
4- 9 PDUC-A011URF0 U Air intake duct 1 AE
4-10 PDUC-A015URP0 U Exhaust duct 1 AM
4-11 PSKR-A010URP0 U Partition plate B 1 AD
4-12 PDUC-A012URP0 U Air duct 1 AG
4-13 LANGQA017URP0 U Grill heater angle 1 AB
4-14 QTANNA001URP0 U Earth plate 1 AB
4-15 PREFHA001URP0 U Grill reflector 1 AN
4-16 LANG-A054WRP0 U Convection heater angle 2 AB
4-17 LANGQA308WRP0 U Convection motor angle 1 AE
4-18 NFANMA003URP0 U Cooling fan 1 AD
4-19 PDUC-A013URP0 U Convection duct 1 AB
4-20 PPIPFA013WRE0 U Pipe 1 AE
4-21 PSKR-A002URP0 U Air separate angle A 1 AC
4-22 PSKR-A003URP0 U Air separate angle B 1 AC
4-23 PSKR-A004URP0 U Air separate angle C 1 AC
4-24 PSKR-A005URP0 U Air separate angle D 2 AC
4-25 PSLDHA001URP0 U Rear heat cover 1 AM
4-26 LANGQA018URP0 U Convection heater angle A 1 AM
4-27 PFPF-A002URE0 U Heat insulating material 1 AL
4-28 PSKR-A006URP0 U Air separate angle E 1 AC
4-29 PSKR-A007URP0 U Air separate angle F 1 AC
4-30 NFANMA011WRP0 J Convection fan 1 AD
4-31 PHOK-A002URF0 U Latch hook 1 AG
4-32 PDUC-A016URF0 U Fan duct 1 AL
4-33 NFANJA038WRE0 U Fan blade 1 AF
4-34 GCOVHA002URP0 U Bottom heater cover 1 AB
4-35 LANGFA001URP0 U Chassis support 1 AB
4-36 NCPL-A040WRE1 U Coupling 1 AP
4-37 PCOVPA309WRE0 U Waveguide cover 1 AC
4-38 PFPF-A003URE0 U Heat insulating material 1 AM
4-39 PFILWA001URP0 U Lamp filter 1 AB
4-40 PPACGA101WRE0 U O-ring 1 AB
4-41 PSLDHA002URP0 U Heater cover right 1 AM
4-42 PSPAGA001WRE0 U Vibration proof cushion 1 AA
4-43 LBNDKA111WRP0 U Capacitor holder 1 AD
4-44 PSKR-A308WRF0 U Rear barrier 1 AH
4-45 LANGFA002URP0 U Cavity support angle 1 AG
DOOR PARTS
5- 1 CDORFS013URK0 U Door panel assembly [R-963(IN)] 1 BN
5- 1 CDORFW015URK0 U Door panel assembly [R-963(W)] 1 BN
5-1-1 GCOVHA024URF0 U Choke cover 1 AL
5-1-2 DDORFA001URK0 U Door panel 1 BH
5-1-3 GWAKPS020URT0 U Door frame [R-963(IN)] 1 AT
5-1-3 GWAKPW031URF0 U Door frame [R-963(W)] 1 AT
5-1-4 JHNDPK001URF0 U Door handle [R-963(IN)] 1 AD
5-1-4 JHNDPS001URT0 U Door handle [R-963(W)] 1 AD
5-1-5 LSTPPA017URF0 U Latch head 1 AG
5-1-6 MSPRTA197WREZ U Latch spring 1 AC
5-1-7 PGLSPA023URR0 U Front door glass [R-963(IN)] 1 AW
5-1-7 PGLSPA022URR0 U Front door glass [R-963(W)] 1 AW
5-1-8 XEBSD30P06000 U Screw : 3mm x 6mm 9 AA
5- 2 LSTPPA018URF0 U Door stopper 1 AB
MISCELLANEOUS
6- 1 FROLPA060WRK0 U Roller stay 1 AS
6- 2 NTNT-A040WRE0 U Turntable tray 1 AZ
6- 3 FAMI-A003URK0 U Square rack (Square shelf) 1 AQ
6- 4 FAMI-A001URK0 U High rack 1 AQ
PARTS LIST
