Sharp R-967 - Parts List

45
Note: The parts marked "∆" may cause undue microwave exposure. / The parts marked "*" are used in
voltage more than 250V. / "§" Mark: Spare parts delivery section
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
PARTS LIST
*
∆*
*
*
ELECTRIC PARTS
C RC-QZA219WRE0 U High voltage capacitor 1 AT
CH RHET-A233WRZZ U Convection heating element 1 AU
CM RMOTEA373WRE0 U Convection motor 1 AV
DM RMOTDA191WRE0 J Damper motor 1 AS
F1 QFS-BA009WRE0 U Fuse 20A 1 AC
F2 QFS-CA025WRE0 U Fuse F8A 1 AC
FM RMOTEA361WRE0 U Fan motor 1 AT
GH RHET-A231WRZZ U Grill heating element 2 AQ
MG RV-MZA264WRE0 U Magnetron 1 BR
OL RLMPTA066WRE0 U Oven lamp 1 AK
SW1 QSW-MA133WRE0 U Monitored latch switch 1 AN
SW2 QSW-MA131WRE0 U Stop switch 1 AK
SW3 QSW-MA133WRE0 U Monitor switch 1 AN
SW4 QSW-MA131WRE0 U Damper switch 1 AK
T RTRN-A016URE1 U High voltage transformer 1 BE
TC1 RTHM-A098WRE0 U Thermal cut-out 125˚C (MG) 1 AK
TC2 RTHM-A109WRE0 U Thermal cut-out 170˚C (GRILL) 1 AM
TC3 RTHM-A109WRE0 U Thermal cut-out 170˚C (CONV.) 1 AM
TTM RMOTDA227WRE0 U Turntable motor 1 AU
1- 1 FH-DZA035WRE0 U High voltage rectifier assembly 1 AP
1- 2 QACCVA004URE2 U Power supply cord 1 AQ
1- 3 FPWBFA309WRE2 U Noise filter 1 AT
1- 4 RTRN-A529WRE0 U TC transformer 1 AV
1- 5 FH-HZA075WRE0 U Thermistor 1 AN
1- 6 FDTCTA208WRKZ U AH sensor 1 AW
CABINET PARTS
2- 1 GCABDA005URP0 U Back plate 1 AU
2- 2 GCABUA038URP0 U Outer case cabinet [R-963(IN)] 1 AU
2- 2 GCABUA037URP0 U Outer case cabinet [R-963(W)] 1 AU
2- 3 GLEGPA028WRE0 U Foot 2 AA
2- 4 GDAI-A003URP0 U Base plate 1 AT
CONTROL PANEL PARTS
3- 1 DPWBFA129URK0 U Power unit 1 BF
3- 1A QCNCMA412DRE0 U 4-pin connector (CN-A) 1 AD
3- 1B QCNCMA433DRE0 U 4-pin connector (CN-B) 1 AM
3- 1C QCNCMA410DRE0 U 2-pin connector (CN-C) 1 AB
3- 1D QCNCMA430DRE0 U 3-pin connector (CN-D) 1 AC
3- 1E QCNCMA230DRE0 U 4-pin connector (CN-E) 1 AC
3- 1F FW-VZA266DREZ U 15-pin wire harness (WH-1) 1 AE
3- 1G FW-VZA267DREZ U 4-pin wire harness (WH-2) 1 AC
C1 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C2 VCEAG31VW108M U Capacitor 1000 uF 35V 1 AE
C3 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C4-5 VCEAG31VW106M U Capacitor 10 uF 35V 2 AB
D1-8 VHD1SS270A/-1 U Diode (1SS270A) 8 AA
D10 RSRCDA013DRE0 U Diode bridge (S1NB10) 1 AE
Q1-2 VS2SB1238//-3 U Transistor (2SB1238) 2 AD
Q3 VSKRC243M//-3 U Transistor (KRC243M) 1 AB
R1 VRD-B12EF242J U Resistor 2.4K ohm 1/4W 1 AA
R2 VRD-B12EF152J U Resistor 1.5K ohm 1/4W 1 AA
R3 VRS-B13AA681J U Resistor 680 ohm 1W 1 AB
R4 VRS-B13AA511J U Resistor 510 ohm 1W 1 AB
R5 VRD-B12EF332J U Resistor 3.3K ohm 1/4W 1 AA
R6 VRS-B13AA131J U Resistor 130 ohm 1W 1 AB
RY1 RRLY-A117DRE0 U Relay (DU18D1-1P(M)-R) 1 AG
RY2 RRLY-A122DRZZ U Relay (DU18D1-1P(M)-R-S) 1 AG
RY3-4 RRLY-A113DRE0 U Relay (DU24D1-1P(M)-R) 2 AG
RY5-8 RRLY-A080DRE0 U Relay (OJ-SH-124LM) 4 AG
SP1 RALM-A014DRE0 U Buzzer (PKM22EPT) 1 AG
VRS1 RH-VZA034DRE0 U Varistor (10G471K) 1 AD
ZD1 VHEHZ161///-1 U Zener diode (HZ16-1) 1 AB
ZD2 VHEHZ201///-1 U Zener diode (HZ20-1) 1 AB
3- 2 DPWBFC039WRKZ U CPU unit 1 BC
3- 3 LHLD-A010URF0 U LED holder 1 AM
3- 4 PSHEPA647WRE0 U LCD sheet 1 AL
3- 5 FUNTKC104URE0 U Key unit [R-963(W)] 1 AS
3- 5 FUNTKC105URE0 U Key unit [R-963(IN)] 1 AS
3- 6 GCOVHA023URF0 U Key fixing frame 1 AL
3- 7 HDECQK001URF0 U Panel sash [R-963(IN)] 1 AR
