Sharp R-980E User Manual

R-980E
39
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
∆
∆
∆
∆
*
1. MODEL NUMBER 3. PART NO.
2. REF. NO. 4. DESCRIPTION
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
4-33 PDUC-A270WRF0 Cooling fan duct 1 AL
4-34 LANGFA089WRW0 Chassis support 1 AE
4-35 MHNG-A165WRM0 Oven hinge (Upper) 1 AE
4-36 NBLTKA005WRE0 Convection fan belt 1 AF
4-37 LANGQA474WRP0 Noise unit angle 1 AG
4-38 PCUSUA196WRP0 Cushion 2 AD
4-39 PCUSUA425WRP0 Damper duct cushion 1 AG
4-40 PCUSGA236WRP0 Cushion 1 AC
4-41 PSKR-A171WRW0 Magnetron air guide 1 AE
4-42 PFPF-A064WRE0 Thermal protection sheet 1 AF
DOOR PARTS
5 CDORFA778WRK0 Door panel assembly complete 1 BV
5- 1 DDORFA820WRY0 Door panel 1 BD
5- 2 PGLSPA499WRE0 Door glass 1 AN
5- 3 GCOVHA155WRF0 Choke cover 1 AP
5- 4 GWAKPA494WRR0 Door frame 1 AZ
5- 5 LANGKA845WRW0 Glass bracket 2 AF
5- 6 LANGKA851WRT0 Latch angle 1 AF
5- 7 LSTPPA169WRF0 Latch head 1 AH
5- 8 MSPRTA192WRE0 Latch head spring 1 AC
5- 9 XCPSD40P08000 Screw; 4mm x 8mm 2 AA
5-10 XEPSD30P08XS0 Screw; 3mm x 8mm 5 AA
5-11 XEBSD30P08000 Screw; 3mm x 8mm 11 AA
MISCELLANEOUS
6- 1 FAMI-A088WRM0 Low rack (Broiling trivet) 1 AW
6- 2 FAMI-A087WRM0 High rack (Baking rack) 1 AW
6- 3 TCADCA546WRR0 Cook book 1 AZ
6- 4 FW-VZB635WRE0 Thermistor harness 1 AT
6- 5 FW-VZB622WRE0 Main wire harness 1 BB
6- 6 QW-QZA202WRE0 High voltage wire A 1 AK
6- 7 TINSEA894WRRZ Operation manual 1 AM
6- 8 TSPCND083WRRZ Name plate 1 AE
6- 9 TCAUHA214WRR0 K caution label 1 AF
6-10 TLABNA226WRR0 Menu label 1 AE
SCREWS, NUTS AND WASHERS
7- 1 XOTWW40P10000 Screw; 4mm x 10mm 14 AA
7- 2 XOTSE40P12000 Screw; 4mm x 12mm 4 AA
7- 3 XCTWW40P08000 Screw; 4mm x 8mm 2 AA
7- 4 XHTSD40P08RV0 Screw; 4mm x 8mm 5 AA
7- 5 LX-CZ0052WRE0 Special screw 2 AA
7- 6 XWVSD60-07000 Washer; 6mm x 0.7 mm 1 AA
7- 7 LX-WZA004WRE0 Washer 1 AA
7- 8 LX-CZA020WRE0 Special screw 6 AA
7- 9 XBPSD30P14K00 Screw; 3mm x 14mm 1 AA
7-10 XBPSD40P25000 Screw; 4mm x 25mm 2 AA
7-11 XBTWW40P06000 Screw; 4mm x 6mm 7 AA
7-12 XCTSD40P08000 Screw; 4mm x 8mm 7 AA
7-13 LX-CZA060WRE0 Special screw 1 AA
7-14 XBPSD40P06KS0 Screw; 4mm x 6mm 2 AA
7-15 LX-WZA022WRE0 Washer 1 AB
7-16 XCPSD40P08000 Screw; 4mm x 8mm 5 AA
7-17 XCPSD30P06000 Screw; 3mm x 6mm 5 AA
7-18 XOTSD40P12RV0 Screw; 4mm x 12mm 11 AA
7-19 XFPSD40P08K00 Screw; 4mm x 8mm 4 AA
7-20 LX-CZA030WRF0 Special screw 2 AC
7-21 XCBWW30P06000 Screw; 3mm x 6mm 4 AA
7-22 XFPSD40P08000 Screw; 4mm x 8mm 5 AA
7-23 XFPSD60P14JS0 Screw; 6mm x 14mm 2 AB
7-24 XOTSD40P12000 Screw; 4mm x 12mm 7 AA
7-25 XFPSD30P08000 Screw; 3mm x 8mm 2 AA
7-26 XNESD40-32000 Nut; 4mm x 3.2mm 2 AA
7-27 XNEUW40-32000 Nut; 4mm x 3.2mm 1 AA
7-28 XWSUW40-10000 Washer; 4mm x 1 mm 1 AA
