23
SJ-D59M/P60M
SJ-D64M/P65M
SJ-D69M/P70M
COOLING UNIT
Figure C-1. Cooling unit
Hot pipe L
(Side condenser)
Hot pipe
(DP-condenser)
Hot pipe R
(Side condenser)
Evaporator
Suction pipe
Sub. condenser
Compressor
Capillary tube
Dryer
Back condens
er
Mark: Refrigerant flow
Mark: Brazing portion
