Sharp SJ-XG690GSL

EN-3
EN
Two-way fresh room door
Description
1. Freezer light
<Only for SJ-XG690G, SJ-XG690M,
SJ-XG740G>
2. Movable ice maker
<Only for SJ-XG640M, SJ-
XG690G, SJ-XG690M>
3. Freezer shelf (Upper)
4. Freezer shelf (Bottom)
5. Freezer case
Move the partition to t the
size of food.
6. Two-way fresh room door
7. Fresh shelf
8. Deodorizing unit
Deodorizing catalyst is installed on the routes of
cold air. There is no need to operate and clean.
9. Refrigerator light
10. Refrigerator shelf
11. Hybrid cooling panel
The panel cools the refrigerator compartment
indirectly from the rear. In this way, food is cooled
gently without being exposed to cold air ow.
12. Fruit and vegetable shelf
13. Fruit and vegetable crisper
14. Adjustable foot
15. Magnetic door seal
16. Control panel
17. Freezer door pocket
18. In-door ice maker
<Only for SJ-XG740G>
(This ice maker is packed inside the freezer
compartment. Refer to the next page ”After
cleaning“ to install.)
19. Water cup
<Only for SJ-XG740G>
(The water cup is packed inside the freezer case.
Make sure to put the cup on the position indicated
in the picture above to use.)
20. Egg pocket
21. Refrigerator pocket (Upper)
22. Bottle pocket
23. Refrigerator pocket (Bottom)
If you wish to store large items within your
refrigerator
• You may remove any shelves or any pockets numbered
2,3,5,6,7,10,13,17, 18, 19, 20, 21, 22, 23 in the picture
above.
• Cooling performance is not inuenced even if you use the
refrigerator in the above situation.
Use the space as
refrigerator room.
Use the space as
fresh room.
How to open the two-way fresh room door
1) Lift up the door.
2) Insert the door into the frame and
push it back to the stopper. It is
locked properly.
Open Close
SJ-XG740G,SJ-XG740M
SJ-XG640M, SJ-XG690G,SJ-XG690M
1
3
4
5
7
6
8
9
1
1
14
14
13
15
19
18
15
16
20
22
23
12
10
1
3
4
2
5
7
6
8
9
11
14
14
13
15
15
17
16
20
22
23
12
10
21
21
17
Partition
Freezer case
Partition
Freezer case
Open Close
SJ-XG740G
