REPLACEMENT PARTS LIST

NOTE:

When ordering replacement part(s), please use part number(s) shown in this part list.

Do not use description of the part.

or Model:

7-1

SMC 1452CH

Ref No. Midea Part No. Part Name&Description Pcs/Set Remarks

A00 9KL12270000026356 ASS'Y CAVITY 1

A01 9KL12570000001036 SPLASH COVER 1

B01 9KL12270000005139 BASE PLATE 1

B02 9KL12170000000192 FOOT 4

B03 9KL12270000006167 ASS'Y HINGE *LOWER 1

C00 9KL17270000B50587 ASS'Y CONTROL 1

C01 9KL12170000020866 PANEL CONTROL 1

C02 9KL12270000026680 DECO. C/PANEL 1

C05 9KL16070000006069 DECORATION 1

C26 9KL17170000015180 MEMBRANE SWITCH CIRCUIT 1

C18 9KL17170000013940 PCB ASS'Y 1

D00 9KL12270000B34521 ASS'Y DOOR 1

D01 9KL12270000003835 ASS'Y DOOR FRAME 1

D02 9KL12170000003877 LATCH 1

D03 9KL12970000000365 LATCH SPRING 1

D04 9KL12270000006147 ASS'Y HINGE *UPPER 1

D05 9KL12170000009509 DOOR FILM 1

D06 9KL12570000A16902 BARRIER SCREEN *O 1

D07 9KL12170000020867 PANEL DOOR 1

D08 9KL12170000009546 DOOR GASKET 1

D09 9KL12270000B33305 DECO. D/PANEL 1

D15 9KL12270000026681 DECO. HANDLE 1

D16 9KL12170000020865 HANDLE 1

E01 9KL17470000000819 MAGNETRON 1 2M392J

E05 9KL17470000003507 H.V.TRANSFORMER 1

E06 9KL17470000000696 H.V.CAPACITOR 1

E07 9KL17470000001007 H.V.DIODE 1
