REPLACEMENT PARTS LIST

or Model:

7-2

SMC 1452CH

Ref No. Midea Part No. Part Name&Description Pcs/Set Remarks

E10 9KL17170000004595 NOISE FILTER 1

E11 9KL17470000001552 FUSE 1

E13 9KL17470000002369 LAMP 1

E16 9KL17470000000183 POWER CORD 1

E32 9KL17470000001488 THERMOSTAT 120/80℃ *H 1

E35+A16 9KL17470000000245 ASS'Y THERMOSTAT 1

L01 9KL12170000003401 LATCH BOARD 1

L02 9KL12170000010256 INTERLOCK LEVER 1

L03 9KL17470000002317 MICROSWITCH INTERLOCK 1

L04 9KL17470000002299 MICROSWITCH MONITOR 1

L05 9KL17470000005484 HARNESS MAIN 1

T01 9KL11002014000014 TURNTABLE MOTOR 1

T02 9KL12170000000430 COUPLER 1

T03 9KL12170000004310 ASS'Y RING ROTATING 1

T04 9KL12570000001006 GLASS TRAY 1

W01 9KL12170000004303 FAN GUIDE 1

W02 9KL12170000000206 FAN 1

W03 9KL11002017000366 FAN MOTOR 1

W04 9KL12270000000175 LAMP COVER 1

W10 9KL12170000000653

AIR GUIDE 1

Y30 9KL17170000005319 ASS'Y SENSOR 1

Z01 9KL12270000006211 H.V.C HOLDER 1

Z22 9KL12670000000424 SPONGE 2

Z22 9KL12670000000424 SPONGE 1

Z24 9KL12270000005661 CASE OUT 1

Z39 9KL12170000003995 PLASTIC NAIL 1

9KL16170000A50816 MANUAL USER 1

9KL16370000A00007 BIG PLASTIC BAG 1

9KL16270000A49032 CARTON BOX 1

9KL16370000000463 PACKING *T 1

9KL16370000000457 PACKING *U 1
