Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
163
TU-GA1U-S
1 CANGTA128WJ01 J Rear Panel Ass’y
1-1 LANGTA128WJFW J Rear Panel
1-2 HiNDPA831WJSA J Indication Label
1-3 QEARZA020WJFW J Earth Spring, x2 AC
2 CCABAA469WJ02 J Chassis Frame Ass’y
2-1 GCABAA469WJFW J Chassis Frame
2-2 LANGTA106WJFW J Sub Chassis Frame
2-3 LANGTA107WJFW J Stand Reinforcement Angle
2-4 LHLDW1121GEZZ J Wire Holder, x2 AB
2-5 LHLDWA023WJKZ J Wire Holder, x1 AC
2-6 LHLDWA032WJZZ J Wire Holder, x1 AD
2-7 QEARZA031WJFW J Earth Spring, x1
2-8 XJPSN30P08XS0 J Screw AA
3 CCABBA334WJ04 J Bottom Cabinet Ass’y
3-1 Not Available – Bottom Cabinet —
3-2 GLEGGA034WJZZ J Rubber Leg, x4 AD
3-3 TLABMA957WJZZ J Model Label
4 CCABBA407WJ01 J Top Cabinet Ass’y
4-1 Not Available – Cabinet —
4-2 TCAUHA050WJZZ J Caution Card AE
5 CHLDZA240WJ01 J Fan Holder Ass’y AH
5-1 Not Available – Fan Holder —
5-2 PSPAGA133WJZZ J Spacer, x4 AB
6 CHLDZA306WJ01 J Fan Holder Ass’y AH
6-1 Not Available – Fan Holder —
PSPAGA133WJZZ J Spacer, x4 AB
7 CPNLCA122WJ02 J Front Panel Ass’y
7-1 Not Available – Front Panel —
7-2 GCOVAA638WJSB J B-CAS Card Cover
7-3 GDORFA091WJSA J Door
7-4 HDECQA333WJSA J LED Decoration Cover
7-5 HiNDPA758WJSB J PC CARD Indication Label
7-6 HiNDPA832WJSA J Terminal Indication Label
7-7 JBTN-A252WJKB J Power Button
7-8 LANGTA121WJFW J Hinge Angle, x2
7-9 LHLDZ3057GEZZ J Magnet Catch, x2 AE
7-10 LHLDZA323WJSA J Hinge Fixed Holder, x3 AL
7-11 MHNG-1072CEZZ J Hinge, x3 AH
7-12 PSPAGA191WJZZ J Spacer, x2
7-13 PSPAZ0457CESA J Spacer, x1 AA
7-14 TLABZA635WJZZ J ”Energy Star” Label
7-15 XEBSN30P08000 J Screw, x7 AA
8 CSLDMA325WJ01 J Radiating Shield Ass’y
8-1 PSLDMA325WJFW J Radiating Shield
8-2 PRDARA103WJFW J Heat Sink-A
8-3 PRDARA104WJFW J Heat Sink-B
9 CANGTA118WJ01 J Tuner Angle Ass’y
9-1 LANGTA118WJFW J Tuner Angle
9-2 PSPAHA328WJZZ J Spacer
9-3 QEARZA058WJZZ J Gasket, x2
10 GCOVAA624WJKB J Side Cover(L)
11 GCOVAA625WJKB J Side Cover(R)
12 GCOVAA678WJKA J SD Cover AE
13 GCOVH1335CEZZ J Modular Jack Cover AD
14 LANGFA094WJFW J MAIN PWB Angle
15 LANGTA111WJN1 J CARD PWB Angle
16 LBSHZA003WJZZ J Fan Bush, x8 AD
17 LHLDW1009CEZZ J Wire Holder, x1 AA
18 LHLDW1046CEZZ J Wire Holder, x1 AA
19 LHLDW1060CEZZ J Wire Holder, x1 AB
20 LHLDW1081GEZZ J Wire Holder, x2 AB
21 LHLDW1090GEZZ J Wire Holder, x1 AB
22 LHLDWA038WJZZ J Wire Holder, x1 AC
23 LX-BZ3434CEFN J Screw, x2 AB
24 LX-NZ3047GEZZ J Tuner Nut, x3 AA
25 NFANR0120CEZZ J Cooling Fan(S) AU
26 NFANR0126CEZZ J Cooling Fan(L) AT
27 NSFTZ0134CEFW J Shaft Screw, x6 AD
28 PSLDMA303WJFW J Front Shield AL
29 PSLDMA324WJFW J TMDS Shield AG
30 PSLDMA342WJFW J PC Card Shield
31 PSLDMA425WJFW J RCA Shield
32 PSPAZA399WJKA J Spacer, x1 AS
33 DUNTKC259FE05 – AV SUB Unit —
34 DUNTKC261FE05 – TMDS TERMINAL Unit —
35 DUNTKC266FE02 – CARD Unit —
36 DUNTKC267FE15 – DVI TERMINAL Unit —
37 DUNTKC427FE12 – CPU Unit —
38 DUNTKC483DE02 – FRONT Unit —
39 DUNTKC484DE02 – AUDIO-I/F Unit —
40 DUNTKC619FE05 – MAIN Unit —
41 DUNTKC663FE01 – AV Unit —
42 RDENCA064WJN1 – POWER Unit —
43 RDENCA074WJN1 – DC/DC CONVERTER Unit —
44 B2SX4102BT J 1BIT AMP. Unit BU
45 QCNW-C598WJPZ J Connecting Cord
46 QCNW-C033WJQZ J Connecting Cord AF
47 QCNW-C036WJQZ J Connecting Cord
48 QCNW-C026WJQZ J Connecting Cord AH
49 QCNW-C030WJPZ J Connecting Cord AF
50 QCNW-C011WJPZ J Connecting Cord AS
51 QCNW-C014WJQZ J Connecting Cord AG
52 QCNW-C018WJPZ J Connecting Cord AR
53 QCNW-C023WJQZ J Connecting Cord AE
54 QCNW-C024WJQZ J Connecting Cord
55 QCNW-C025WJQZ J Connecting Cord
56 QCNW-C031WJQZ J Connecting Cord
57 QCNW-C034WJQZ J Connecting Cord AG
58 QCNW-C035WJQZ J Connecting Cord AE
59 QCNW-C041WJQZ J Connecting Cord
60 QCNW-C523WJQZ J Connecting Cord
61 QCNW-C524WJQZ J Connecting Cord
62 Not Available – Serial No. Label —
63 QEARBA009WJFW J Earth Spring, x1
64 QEARZ0056CEFW J Earth Spring, x4 AC
65 XBPSN30P06000 J Screw, x4 AA
66 XEBSN26P06000 J Screw, x1 AA
67 XEBSN30P08000 J Screw, x4 AA
68 XJPSN30P08XS0 J Screw, x85 AA
69 LANGTA110WJFW J TMDS PWB Angle
70 LHLDWA023WJKZ J Wire Holder, x1 AC
71 LHLDW1121GEZZ J Wire Holder, x1 AB
72 LANGTA116WJN1 J DVI PWB Angle
73 LHLDWA035WJZZ J Wire Holder, x1 AC
74 LANGTA109WJN1 J AV PWB Angle
75 LHLDFA021WJZZ J Wire Holder, x1 AC
76 LHLDW1090GEZZ J Wire Holder, x2 AB
CABINET AND MECHANICAL PARTS
