Sharp VC-A560UA - Page 29

29
VC-A560U(A)/A560U/A560U(B)
VC-H960U/H960U(B)/H961U
2. Frame R, Frame L, Drive Arm R, Drive Arm L, Upper
Plate.
4-25 ASSEMBLY OF CASSETTE HOUSING
1. Proof lever Proof lever spring and Holder R
Figure 4-41.
MSPRD0215AJFJ
*Proof lever spring fixing direction designated.
LANGF9661AJFW
Top surface should be free from scratches or soil.
