Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
86
VC-MH75HM
INTEGRATED CIRCUITS
IC1701 VHiMSP3417G-1Q V I.C. AY
PACKAGED CIRCUITS
X1701 RCRSB0249GEZZ+ V Crystal AF
COILS
L1703 VP-XF100J0000+ U Peaking 10µH
L1704 VP-XF100J0000Y V Peaking 10µHAB
CAPACITORS
C1701 VCCSD41HL220JY U 22p 50V Ceramic
C1702 VCCCCY1HH470JY V 47p 50V Ceramic AA
C1704 VCKYCY1HF103ZY V 0.01 50V Ceramic AA
C1705 VCEA9M1CW106M+ V 10 16V Electrolytic AB
C1706 VCKYCY1HF103ZY V 0.01 50V Ceramic AA
C1707 VCEA9M1CW106M+ V 10 16V Electrolytic AB
C1708 VCEA9M0JW226M+ V 22 6.3V Electrolytic AB
C1709 VCEA9M1AW226M+ V 22 10V Electrolytic AB
C1710 VCCCCY1HH5R0CY V 5p 50V Ceramic AA
C1711 VCCCCY1HH6R0DY V 6p 50V Ceramic AA
C1712 VCKYCY1HF103ZY V 0.01 50V Ceramic AA
C1713 VCKYCY1HF103ZY V 0.01 50V Ceramic AA
C1714 VCEA9M1HW105M+ V 1 50V Electrolytic AB
C1715 VCKYCY1HF103ZY V 0.01 50V Ceramic AA
C1718 VCEA9M0JW226M+ V 22 6.3V Electrolytic AB
C1720 VCCCCY1HH470JY V 47p 50V Ceramic AA
MISCELLANEOUS PARTS
å ACC901 QACCB5014UMZZ U AC Cord AQ
å F901 QFS-C2025CEZZ V Fuse, 2A/250V AD
FB101 RBLN-0043CEZZY V Ferrite Bead AB
FB204 RBLN-0090GEZZY V Ferrite Bead AB
FB205 RBLN-0043CEZZY V Ferrite Bead AB
FB206 RBLN-0043CEZZY V Ferrite Bead AB
FB701 RBLN-0090GEZZY V Ferrite Bead AB
FB901 RBLN-0090GEZZY V Ferrite Bead AB
FB903 RBLN-0043CEZZY V Ferrite Bead AB
FB931 RBLN-0043CEZZY V Ferrite Bead AB
å FH901 QFSHD1017CEZZ+ V Fuse Holder AC
å FH902 QFSHD1018CEZZ+ V Fuse Holder AC
J201 QJAKFA005WJZZ U Jack
P701 QPLGZ1283GEZZ V Plug AE
P809 QPLGN0459REZZ V Plug AG
P901 QPLGN0269GEZZ V Plug AB
P1701 QPLGZ0809REZZ V Plug AC
PDA301 PSLDM4594AJFW V Shield AD
RMC801 RRMCU0086GEZZ V Remote Receiver AQ
S701 QSW-F0042AJZZ V Rec Tip Switch AG
S704 QSW-RA001WJZZ V Switch AF
S801 QSW-K0004AJZZ+ V Switch, POWER AB
S802 QSW-K0004AJZZ+ V Switch,EJECT AB
S803 QSW-K0004AJZZ+ V Switch, MENU AB
S804 QSW-K0004AJZZ+ V Switch, CH- AB
S805 QSW-K0004AJZZ+ V Switch, SET AB
S806 QSW-K0004AJZZ+ V Switch, CH+ AB
S807 QSW-K0004AJZZ+ V Switch, PAUSE AB
S808 QSW-K0004AJZZ+ V Switch, REC AB
SC301 QSOCNA006WJZZ V Socket AD
SC601 QSOCN0611REN1 V Socket AC
SC602 QSOCZ0293GEZZ V Socket AC
SC803 QSOCZ0457GEZZ V Socket AC
SC2503QSOCN2495REZZ U Socket
TP201 QPLGN0447REZZ V Plug AA
LC8001RLCDDA005WJZZ V LCD Display
W8002 PSHEP0349AJZZ V Sheet AC
DUNTB106TEX1
OPERATION Unit
RESISTORS
R881 VRS-CY1JF103JS V 10k 1/16W Metal Oxide AA
R882 VRS-CY1JF103JS V 10k 1/16W Metal Oxide AA
R883 VRS-CY1JF223JS V 22k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
S881 QSW-K0004AJZZ+ V Switch, PLAY AB
S882 QSW-K0004AJZZ+ V Switch, STOP AB
S884 QSW-K0004AJZZ+ V Switch, REW AB
S886 QSW-K0004AJZZ+ V Switch, FF AB
SC881 QSOCZ0450CEZZ V Socket, 4pin(OA) AC
DUNTB107TEX1
BACK LIGHT Unit
TRANSISTORS
Q851 VS2PD601AR/-1Y V 2PD601AR AB
Q852 VS2PD601AR/-1Y V 2PD601AR AB
DIODES
D8851 RH-PXA021WJZZ+ V PhotoDiode AD
D8852 RH-PXA021WJZZ+ V PhotoDiode AD
D8853 RH-PXA021WJZZ+ V PhotoDiode AD
RESISTORS
R8853 VRD-RA2BE391JY V 390 1/8W Carbon AA
R8854 VRD-RA2BE391JY V 390 1/8W Carbon AA
R8855 VRS-CY1JF222JS V 2.2k 1/16W Metal Oxide AA
R8856 VRS-CY1JF222JS V 2.2k 1/16W Metal Oxide AA
R8857 VRD-RA2BE391JY V 390 1/8W Carbon AA
R8858 VRD-RA2BE391JY V 390 1/8W Carbon AA
R8859 VRD-RA2BE391JY V 390 1/8W Carbon AA
R8860 VRD-RA2BE391JY V 390 1/8W Carbon AA
MISCELLANEOUS PARTS
P883 QPLGZ0457GEZZ V Plug, 4pin(AM) AD
DUNTKB111TEV3
NICAM/IGR Unit
