Sharp VC-MH80

VGMH80
VC47lH90
HEAD AMPLIFIER
: Remove 1 screw @.
HQLDE+
ANTENN A : Remove ‘1 screw a.
MECHANISM
: Disconnect the FFCs from 2
CHASSISI
sockets @ .
CASSETTE
Disconnect the connectors
CONTROLLER
from 2 sockets @. Take the
ASSEMBLY
relay PWB out of the socket @
Rmove 1 screw @ and detach
the head.amplifier unit.
Disconnect the FFC from the
socket @ . Remove 2 screws @
from:behind the main PWB.
Lift the mechanism chassis/
cassette controller assembly
vertically to take it out of the
main PWB.
CASSETTE
CONTROLLER
: Remove 2 screws @.
CASSETTE
CONTROLLER
/
HEAD AMPLIFIER
CHASSIS/CASSETTE
CONTROLLER
ASSEMBLY
-ANTENNA
TERMINAL BOX
