Part Names
For details on the use of each part, refer to the page number indicated in the
brackets.
Front view
When the cassette compartment door is open
Operation Summary
Terminal cover
Microphone
Zoom lens
Speaker
AUDIO/VIDEO jack
[pp. 22, 49]
DC IN jack [pp. 8, 9]
Shoulder strap loop
[p. 17]
Lithium battery holder
[p. 11]
Cassette holder [p. 10]
Lens hood [p. 32]
Cassette compartment door
release [p. 10]
Cassette compartment door
[p. 10]
