Sharp VT-G14 - Page 107

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
122
VT-G14
VT-G21
R624 VRD-RM2HD2R7J R 2.7 1/2W Carbon AA
R625 VRD-RM2HD2R7J R 2.7 1/2W Carbon AA
R626 VRS-CY1JF103J R 10k 1/16W Metal Oxide AA
R788 VRD-RA2BE223J R 22k 1/8W Carbon AA
R789 VRD-RA2BE563J R 56k 1/8W Carbon AA
R790 VRD-RA2EE104J R 100k 1/4W Carbon AA
R791 VRD-RA2BE104J R 100k 1/8W Carbon AA
å R1701 VRC-UA2HG275K R 2.7M 1/2W Solid AA
MISCELLANEOUS PARTS
CN1701 QCNW-2254PEZZ J Connecting Cord AG
å F601 QFS-J1023CEZZ R IC Protector (1A) AE
å F1701 QFS-C3229CEZZ R Fuse T3.15A (250V) AD
FB301 RBLN-0037CEZZ R Ferrite Bead AB
FB601 RBLN-0037CEZZ R Ferrite Bead AB
FH1701 QFSHD1017CEZZ R Fuse Holder AC
FH1702 QFSHD1018CEZZ R Fuse Holder AC
J401 QTANJ0429CEZZ R AV Terminal, Rear AH
P201 QPLGN0261CEZZ R Plug, 2-pin (TP201) AB
P401 QPLGN0941CEZZ R Plug, 9-pin (AN) AC
P402 QPLGN0561CEZZ R Plug, 5-pin (AV) AB
P601 QPLGN0461CEZZ R Plug, 4-pin (H) AB
P602 QPLGN0603CEZZ R Plug, 6-pin (F) AB
P604 QPLGN1041CEZZ R Plug, 10-pin (AM) AC
P754 QPLGN0361CEZZ R Plug, 3-pin (PC) AB
P1701 QPLGN0269GEZZ R Plug, 2-pin (A) AB
SC201 QSOCN0785CEZZ R Socket, 7-pin (IA) AC
SC202 QSOCN0785CEZZ R Socket, 7-pin (IB) AC
SC203 QSOCZ1040CEZZ R Socket, 10-pin (MA) AD
SC204 QSOCZ1040CEZZ R Socket, 10-pin (MB) AD
HM601 LX-GZ3001PEZZ J HATOME AB
HM602 LX-GZ3001PEZZ J HATOME AB
HM603 LX-GZ3001PEZZ J HATOME AB
HM604 LX-GZ3001PEZZ J HATOME AB
HM605 LX-GZ3001PEZZ J HATOME AB
HM606 LX-GZ3001PEZZ J HATOME AB
HM607 LX-GZ3001PEZZ J HATOME AB
HM608 LX-GZ3002PEZZ J HATOME AB
HM609 LX-GZ3002PEZZ J HATOME AB
HM610 LX-GZ3002PEZZ J HATOME AB
HM611 LX-GZ3002PEZZ J HATOME AB
HM612 LX-GZ3002PEZZ J HATOME AB
HM613 LX-GZ3002PEZZ J HATOME AB
LB601 LX-BZ3100CEFD R Screw, for Q602 AA
RDA501 PRDAR0223PEFW J Heat Sink, for IC501 AF
RDA601 PRDAR0224PEFW J Heat Sink, for Q602 AF
LHLDW1002PEZZ J Holder AB
LX-TZ3004CEFD R Screw, for T602 AA
LX-BZ3100CEFD R Screw, for IC501 AA
PWB-B: DUNTK9570WEV0/V1
TUNER/DEF UNIT (Continued)
PWB-C: DUNTK9569FMV0/V1
POWER UNIT
INTEGRATED CIRCUITS
å IC701 VHiSTRF6654-1 R Power Control AX
å IC751 VHiSE115N//-1 R Error Detector AF
TRANSISTORS
Q701 VS2SC2229O/1E R 2SC2229(O) AD
Q702 VSDTC144ES/-1 R DTC144ES AB
Q703 VSDTC144ES/-1 R DTC144ES AB
Q751 VSDTC144ES/-1 R DTC144ES AB
Q752 VS2SA1266-Y-1 R 2SA1266(Y) AA
Q753 VS2SC3198-G-1 R 2SC3198(G) AA
Q754 VS2SA1266-Y-1 R 2SA1266(Y) AA
Q755 VSDTC144ES/-1 R DTC144ES AB
Q757 VSKTA1024-Y-1 R KTA1024(Y) AD
Q758 VS2SC2229O/1E R 2SC2229(O) AD
Q761 VS2SD1944K/-1 R 2SD1944(K) AE
DIODES
D701 RH-DX0386CEZZ R Diode AG
D705 VHD1SS82///1A R Diode AC
D706 VHD1SS82///1A R Diode AC
D707 RH-DX0164CEZZ R Diode AC
D708 VHD1SS119//-1 R Diode AB
D709 RH-EX0601GEZZ R Zener Diode, 3.6V AA
D710 RH-DX0066GEZZ R Diode AB
D711 RH-EX0676GEZZ R Zener Diode, 31.7V AA
D712 RH-DX0279CEZZ R Diode AB
D713 RH-EX0676GEZZ R Zener Diode, 31.7V AA
D714 RH-EX0656GEZZ R Zener Diode, 19.7V AC
D751 RH-DX0349CEZZ R Diode AC
D752 RH-DX0461CEZZ R Diode AG
D753 RH-DX0473CEZZ R Diode AK
D754 RH-DX0473CEZZ R Diode AK
D755 RH-EX0645GEZZ R Zener Diode, 13.8V AB
D756 VHD1SS119//-1 R Diode AB
D759 RH-EX0610GEZZ R Zener Diode, 4.8V AA
D760 VHD1SS119//-1 R Diode AB
D763 RH-EX0608GEZZ R Zener Diode, 4.6V AA
D764 RH-DX0460CEZZ R Diode AF
D766 VHD1SS119//-1 R Diode AB
D767 RH-EX0645GEZZ R Zener Diode, 13.8V AB
D768 RH-EX0665GEZZ R Zener Diode, 24.2V AA
D769 VHD1SS119//-1 R Diode AB
D770 RH-EX0631GEZZ R Zener Diode AA
D771 VHD1SS119//-1 R Diode AB
D772 VHD1SS119//-1 R Diode AB
å IC702 RH-FX0008GEZZ R Photo Coupler AE
å IC703 RH-FX0008GEZZ R Photo Coupler AE
COILS AND TRANSFORMERS
L751 RCiLP0179CEZZ R Coil 47µH AD
L752 RCiLP0171CEZZ R Coil 10µH AD
å T701 RTRNZ0134PEZZ J Transformer AX
CAPACITORS
C701 RC-KZ0160GEZZ R 0.01 AC250V Ceramic AC
C702 RC-KZ0160GEZZ R 0.01 AC250V Ceramic AC
C703 RC-KZ0160GEZZ R 0.01 AC250V Ceramic AC
C704 RC-EZ1046CEZZ R 220 400V Electrolytic AN
(VT-G14)
C704 RC-EZ0688CEZZ R 330 400V Electrolytic AV
(VT-G21)
C705 RC-QZA821TAYJ R 820p 50V Mylar AB
C706 VCKYPA1HB102K R 1000p 50V Ceramic AA
C707 VCQPSC2JA333K R 0.033 630V Polypro Film AB
C708 VCFPPC3CA182J R 1800p 1.6kV Polypro Film AD
C709 RC-KZ0338CEZZ R 560 2kV Ceramic AD
C710 VCQYTA1HM103J R 0.01 50V Mylar AA
C711 VCKYPA2HB102K R 1000p 500V Ceramic AA
C712 VCEA0A1VW108M R 1000 35V Electrolytic AD
C713 VCEA0A1VW476M R 47 35V Electrolytic AB
