125
VT-G14
VT-G21
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
INTEGRATED CIRCUIT
IC251 VHiBA7357S/-1 R PIF/SIF AR
TRANSISTORS
Q251 VS2SC1906//1E R 2SC1906 AC
Q252 VSDTC144EK/-1 R DTC144EK AB
Q253 VS2SC2412KQ-1 R 2SC2412K AA
Q254 VSDTC144EK/-1 R DTC144EK AB
Q255 VS2SC2412KQ-1 R 2SC2412K AA
Q256 VS2SC2412KQ-1 R 2SC2412K AA
Q257 VSDTC144EK/-1 R DTC144EK AB
Q258 VSDTC144EK/-1 R DTC144EK AB
Q259 VSDTC144EK/-1 R DTC144EK AB
Q260 VSDTC144EK/-1 R DTC144EK AB
Q261 VSDTC144EK/-1 R DTC144EK AB
Q262 VSDTC144EK/-1 R DTC144EK AB
Q263 VS2SC3198-G-1 R 2SC3198(G) AA
DIODES
D251 VHD1SS152//-1 R Diode AB
D252 RH-EX0621GEZZ R Zener Diode, 6.7V AB
D253 RH-DX0027CEZZ R Diode AE
FILTERS AND COILS
CF251 RFiLC0081GEZZ R Ceramic Filter 5.0MHz AD
CF252 RFiLA0042CEZZ R Ceramic Filter 6.0MHz AD
CF253 RFiLA0093CEZZ R Ceramic Filter 6.5MHz AC
L251 VP-XF1R0M0000 R Peaking 1µH AB
L253 VP-XF390K0000 R Peaking 39µH AB
SF251 RFiLC0001PEZZ J S.A.W Filter AS
T253 RCiLD0238CEZZ R Detection Coil AE
T254 RCiLD0239CEZZ R Detection Coil AE
CONTROL
R265 RVR-M4630GEZZ R 47k (B) RF-AGC AB
CAPACITORS
C251 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C252 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C253 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C254 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C255 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C256 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C257 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C258 VCEA0A1HW106M R 10 50V Electrolytic AB
C259 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C260 VCQYTA1HM104J R 0.1 50V Mylar AA
C261 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C262 VCEA0A1HW225M R 2.2 50V Electrolytic AB
C263 VCEA0A1HW475M R 4.7 50V Electrolytic AB
C264 VCQYTA1HM104J R 0.1 50V Mylar AA
C265 VCQYTA1HM472J R 4700p 50V Mylar AB
C266 VCQYTA1HM103J R 0.01 50V Mylar AA
C267 VCCCCY1HH180J R 18p 50V Ceramic AA
C268 VCCCCY1HH180J R 18p 50V Ceramic AA
C269 VCCCCY1HH220J R 22p 50V Ceramic AA
C270 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C271 VCQYTA1HM104J R 0.1 50V Mylar AA
C272 VCCCCY1HH330J R 33p 50V Ceramic AA
C273 VCEA0A1CW476M R 47 16V Electrolytic AB
C274 VCCCCY1HH220J R 22p 50V Ceramic AA
C275 VCCCCY1HH101J R 100p 50V Ceramic AA
C276 VCFYFA1HA684J R 0.68 50V Mylar AD
C277 VCCCCY1HH470J R 47p 50V Ceramic AA
C278 VCCCCY1HH270J R 27p 50V Ceramic AA
RESISTORS
R252 VRS-CY1JF151J R 150 1/16W Metal Oxide AA
R253 VRS-CY1JF680J R 68 1/16W Metal Oxide AA
R254 VRS-CY1JF562J R 5.6k 1/16W Metal Oxide AA
R255 VRS-CY1JF272J R 2.7k 1/16W Metal Oxide AA
PWB-G: DUNTK9573FMV0/V1
IF UNIT
R256 VRS-CY1JF561J R 560 1/16W Metal Oxide AA
R257 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
R258 VRS-CY1JF221J R 220 1/16W Metal Oxide AA
R259 VRS-CY1JF562J R 5.6k 1/16W Metal Oxide AA
R260 VRS-CY1JF222J R 2.2k 1/16W Metal Oxide AA
R261 VRS-CY1JF272J R 2.7k 1/16W Metal Oxide AA
R262 VRS-CY1JF154J R 150k 1/16W Metal Oxide AA
R263 VRS-CY1JF273J R 27k 1/16W Metal Oxide AA
R264 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R266 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R267 VRS-CY1JF222J R 2.2k 1/16W Metal Oxide AA
R268 VRS-CY1JF473J R 47k 1/16W Metal Oxide AA
R269 VRS-CY1JF473J R 47k 1/16W Metal Oxide AA
R270 VRS-CY1JF103J R 10k 1/16W Metal Oxide AA
R271 VRS-CY1JF153J R 15k 1/16W Metal Oxide AA
R272 VRS-CY1JF103J R 10k 1/16W Metal Oxide AA
R273 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R274 VRS-CY1JF222J R 2.2k 1/16W Metal Oxide AA
R275 VRS-CY1JF472J R 4.7k 1/16W Metal Oxide AA
R276 VRS-CY1JF222J R 2.2k 1/16W Metal Oxide AA
R278 VRS-CY1JF393J R 39k 1/16W Metal Oxide AA
R279 VRS-CY1JF822J R 8.2k 1/16W Metal Oxide AA
R280 VRS-CY1JF272J R 2.7k 1/16W Metal Oxide AA
R281 VRS-CY1JF472J R 4.7k 1/16W Metal Oxide AA
R282 VRS-CY1JF472J R 4.7k 1/16W Metal Oxide AA
R283 VRS-CY1JF472J R 4.7k 1/16W Metal Oxide AA
R284 VRS-CY1JF151J R 150 1/16W Metal Oxide AA
R285 VRS-CY1JF392J R 3.9k 1/16W Metal Oxide AA
R286 VRS-CY1JF562J R 5.6k 1/16W Metal Oxide AA
R287 VRD-RM2HD271J R 270 1/2W Carbon AA
R288 VRD-RM2HD221J R 220 1/2W Carbon AA
R290 VRD-RM2HD1R0J R 1 1/2W Carbon AA
R291 VRS-CY1JF332J R 3.3k 1/16W Metal Oxide AA
(VT-G14)
R291 VRS-CY1JF152J R 1.5k 1/16W Metal Oxide AA
(VT-G21)
R292 VRS-CY1JF184J R 180k 1/16W Metal Oxide AA
R293 VRS-CY1JF223J R 22k 1/16W Metal Oxide AA
R295 VRS-CY1JF395J R 3.9M 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
P251 QPLGN0785CEZZ R Plug, 7-pin (IA) AC
P252 QPLGN0785CEZZ R Plug, 7-pin (IB) AC
SLD251 PSLDM0265PEFW J Shield AD
SLD252 PSLDM0266PEFW J Shield AC
TP251 QLUGP0102PEZZ J Lug, Test Point AA
TP252 QLUGP0102PEZZ J Lug, Test Point AA
TP253 QLUGP0102PEZZ J Lug, Test Point AA
