127
VT-G14
VT-G21
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
69 QPLGZ0292GEZZ J Socket (LDG Motor) AE
70 MSPRC0223AJFJ V Azimuth Spring AC
71 MSPRC0224AJFJ V Height Adjusting Spring AC
72 CARMP0059GE01 V I-Roller Arm Ass’yAS
(VT-G21)
73 MSPRD0183GEFJ V I-Roller Arm Spring AC
(VT-G21)
1 LBNDK1011AJZZ V Tension Band Ass’yAH
2 LBOSZ1007AJZZ V Tension Arm Boss AD
4 LBOSZ1006AJZZ V Cassette Stay L AD
5 LCHSM0166AJZZ V Main Chassis Ass’y
(VT-G14) BA
5 LCHSM0170AJZZ V Main Chassis Ass’y (VT-G21) BA
6 LHLDZ2016AJZZ V Loading Motor Block AG
7 LPOLM0063GEZZ J Supply Pole Base Ass’yAM
(VT-G14)
7 LPOLM0070GEZZ J Supply Pole Base Ass’yAK
(VT-G21)
8 LPOLM0064GEZZ J Take-Up Pole Base Ass’yAM
9 MLEVF0518AJZZ V Take-Up Loading AF
Arm Ass’y
10 MLEVF0519AJZZ V Supply Loading AF
Arm Ass’y
11 MLEVF0499AJZZ V Pinch Drive Lever Ass’yAG
12 MLEVF0500GEZZ J Pinch Roller Lever Ass’yAW
15 MLEVF0496AJZZ V Tension Arm Ass’yAK
16 LANGF9620AJFW V A/C Head Plate AG
17 MLEVP0271AJZZ V Shifter Drive Lever AE
18 MLEVP0272AJZZ V Pinch Double Action Lever AD
19 MLEVP0301AJZZ V Reverse Guide Lever Ass’yAL
20 MLEVP0275AJZZ V Reverse Drive Lever AD
21 MLEVP0292AJZZ V Slow Brake Lever AE
22 MLEVP0290AJZZ V Open Lever AD
23 MLEVP0293AJZZ V Clutch Lever AE
24 MLEVP0294AJZZ V Supply Main Brake Ass’yAF
25 MLEVP0295AJZZ V Take-Up Main Brake Ass’yAF
26 CLEVP0287AJZZ V Auto Head Cleaner Ass’yAG
27 MSLiP0010AJZZ V Shifter AH
29 MSPRD0175AJFJ V Reverse Guide Spring 2 AE
30 MSPRT0402AJFJ V Loading Double Action AE
Spring
31 MSPRT0403AJFJ V Pinch Double Action AD
Spring
32 MSPRC0213AJFJ V Earth Spring AC
33 MSPRT0416AJFJ V Tension Spring AD
34 NBLTK0067AJ00 V Drive Belt AE
35 NDAiV1078AJ00 V Reel Disk AE
36 NGERH1293AJZZ V Loading Connect Gear AD
37 NGERH1295AJ00 V Master Cam AE
38 NGERH1294AJZZ V Casecon Drive Gear AD
39 NGERH1270AJZZ V Take-Up Loading Gear AF
40 NGERH1271AJZZ V Supply Loading Gear AD
41 NGERH1272AJZZ V Pinch Drive Cam AE
43 NGERH1299AJZZ V Reel Relay Gear AE
44 NGERW1070AJZZ V Worm Gear AD
45 NGERW1066AJZZ V Worm Wheel Gear AD
46 NiDR-0018AJZZ V Idler Wheel Ass’yAK
47 NPLYV0162AJZZ V Motor Pulley AD
48 NPLYV0163AJZZ V Limitter Pulley Ass’yAM
49 NROLP0131GEZZ J Guide Roller AL
50 NSFTP0032AJZZ V Tension Pole Adjuster AB
51 MSPRC0217AJFJ V Guide Roller Spring AC
52 PREFL1011AJZZ V Light Guide AE
53 QCNW-0247AJZZ V FFC for Drum Motor AG
55 QCNW-0272AJZZ V FFC for A/C Head AF
56 QPWBF5469AJZZ V A/C Head PWB AE
57 QSOCN0605REN1 V Socket, 6-pin AB
58 RHEDT0036AJZZ V Full Erase Head AM
59 RHEDU0088GEZZ J A/C Head Ass’yAV
60 RMOTM1078GEZZ J Loading Motor AP
61 RMOTN2055GEZZ J Capstan Motor BA
62 RMOTP1135GEZZ J Drum Drive Motor AX
63 DDRMW0028TEX3 V Upper and Lower Drum BP
Ass’y
65 QBRSK0041GEZZ V Drum Earth Brush AD
66 XBPSD26P05J00 V Drum Drive Motor AA
Mounting Screw
(SW2.6P+5S)
67 PGiDC0056GEFW J Drum Base AL
68 QPWBF5468AJZZ V PWB (LDG Motor) AE
MECHANISM CHASSIS PARTS
