Sharp VT-G14 - Page 116

131
VT-G14
VT-G21
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
1 CCABA2458WEV0 R Front Cabinet Ass’yBH
1-1 Not Available – Front Cabinet —
1-2 HDECQ0109PESC R Punching Plate AD
1-3 HBDGB0014PESB R Badge, “SHARP” AE
1-4 HDECQ0122PESA R VCR Flap AH
1-5 GCOVA0094PESA R LED Decoration AE
1-6 JBTN-0293PESC R Button, Power AD
1-7 CBTN-0294WEV0 R Button Ass’y, VCR Control AQ
1-7-1 Not Available – Button, VCR Control —
1-7-2 LHLDZ0108PEZZ R Holder AG
1-8 LHLDZ0040PEZZ R Holder, x2 AC
1-9 LX-TZ3004CEFD R Screw, x8 AA
1-10 MSPRC0005PEFW R Spring, for Power Button, x2 AB
1-11 MSPRD0123AJFJ R Spring, for VCR Flap AC
1-12 PSPAH0012PE00 R Spacer, x1 AA
1-14 JBTN-0295PESA R Button, Main Power AC
1-15 LX-TZ0012PEFD R Screw, x4 AC
1-16 VSP9050PB20WA R Speaker, x1 AP
1-17 PSPAH0039PE00 R Spacer AA
1-18 PZETV0024PEKZ R Insulator AF
1-19 PSPAH0053PE00 R Spacer, x3 AD
1-20 PSPAH0034PE00 R Spacer AA
2 CCABB2350WEV0 R Rear Cabinet Ass’yBA
2-1
Not Available – Rear Cabinet —
2-2 LHLDZ0110PEZZ R Holder AC
å 3 QACCZ2008PEZZ R AC Cord AM
4 QCNW-2273PEZZ R Connecting Wire AG
6 PSLDM0250PEFW R Shield Cover (Top) AD
7 PSLDM0272PEFW R Shield (Top) AN
8 PSLDM0273PEFW R Shield (Bottom) AG
9 LANGT0038PEFW R Angle AC
10 QEARC1414PEZZ R Wire, Grounding Strap AK
11 LCHSM0074PEZZ R Main Chassis Frame AU
13 LHLDK0002PEK0 R AC Cord Holder AA
15 PSLDM0253PEFW R Shield Angle AC
16 LHLDW0003PEKZ R Degaussing Coil Holder, x4 AC
17 LHLDW1047PEZZ R Wire Holder, x4 AB
18 LHLDW1019PEZZ R Wire Holder, x6 AB
19 LHLDW1074PEKZ R Wire Holder AD
20 PSPAG0004PEZZ R Wedge (Gum), x3 AB
21 TLABM1402PEZZ R Model Label AC
22 LX-TZ0013PEFD R Screw, for CRT, x4 AD
23 LHLDW1002PEZZ R Wire Holder AB
24 LX-HZ3001PEFD R Screw, x6 AA
25 XEBSD30P12000 R Screw, x22 AA
26 XHPSD30P06WS0 R Screw, x5 AA
27 XTASD40P20000 R Screw, x9 AA
28 XTASD40P20000 R Screw, x2 AA
29 LCHSM0075PEZZ R Power Chassis Frame AP
å 30 VB370BVBK1S-S R Picture Tube (V801) BZ
å 31 RCiLH0140PEZZ R Deflection Yoke (DY601) BC
å 32 RCiLG0031PEZZ R Degaussing Coil (L799) AN
or
RCiLG0080PEZZ R Degaussing Coil (L799) AL
33 PMAGF3006CEZZ R Purity Magnet AK
34 QSW-F0042AJZZ R Rec Tip Switch (S7701) AG
35 QCNW-2243PEZZ J Connecting Wire (H) AF
36 QCNW-2241PEZZ J Connecting Wire (K) AF
37 LANGT0036PEFW R Radiator Angle AC
38 PSLDM0251PEFW R Shield AD
39 RH-PX0223GEZZ R Start/End Sensor AF
40 LHLDZ1759CEKZ R Holder AB
41 LHLDW1074PEKZ R Wire Holder AD
43 QCNW-5240PEN3 R Connecting Wire AD
46 LX-BZ3100CEFD R Screw, x1 AA
47 LX-TZ3004CEFD R Screw, x1 AA
48 PSPAG0022PE00 R Wedge AC
49 LX-WZ0018PEZZ R Washer AB
CABINET MECHANICAL PARTS
MODEL VT-G14
