FUNCTION OF MAJOR MECHANICAL PARTS (BOTTOM VIEW)
No. Function
No. Function
19 Slow brake
20 Master cam
21 Capstan D.D. motor
22 Reel belt
23 Clutch lever
24 Limiter pulley ass'y
(12) Casecon drive gear
26 Shifter
