57
VT-G14
VT-G21
NO
YES
YES
YES
NO
FLOWCHART NO. 1-9
DRUM MOTOR TROUBLESHOOTING
The drum motor fails to run.
Is the voltage more than about 2.6V
applied at pin (7) of connector AD ?
Check the AT5V line.
Is 5V at pin (1) of connector AD ?
NO
Check the AT12V line.
Is 12V at pin (4) of connector AD ?
Check the connection between
connectors AD and ME or
Check/replace the drum motor.
Check between the connector AD
and pin (78) of IC7701, and between
the connector AD and pin (76) of
IC7701.
NO
YES
YES
YES
NO
FLOWCHART NO. 1-10
The drum motor runs only for a few seconds.
Is drum PG signal at pin (3) of AD
connector ?
Check between the connector AD and
all the way up to pin (86) of IC7701.
Is drum PG signal at pin (86) of
IC7701 ?
NO
Check/replace IC7701.
Is H. SW. pulse at pin (18) of
IC7701 ?
Check pin (76) of IC7701.
Check the drum motor.
