Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
114
VT-G14
VT-G21
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual: electrical components having such fea-
tures are identified by "å" in the Replacement Parts Lists.
The use of a substitute replacement part which does not have the
same safety characteristics as the factory recommended replace-
ment parts shown in this service manual may create shock, fire or
other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
MARK ★: SPARE PARTS-DELIVERY SECTION
Ref. No. Part No. ★ Description Code
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
PICTURE TUBE
PWB-A: DUNTK9568WEV0/V1
MAIN UNIT
INTEGRATED CIRCUITS
IC351 VHiTDA7056A-1 R Audio Amp. AP
IC780 VHiPQ09RD11-1 R 9V Regulator AG
IC801 VHiTB1226DN-1 R PAL/SECAM/NTSC BB
IC1001 RH-iX3109CEZZ R MPU BE
IC1002 VHiS24C04A/-1 R EEP ROM AL
IC1003 VHiPST600D/-1 R Reset-IC AD
IC1004 VHiKiA7045A-1 R 5V Regulator AE
IC2201 VHiNN3572F/-1 R YC/Audio Processor BA
IC3301 VHiAN3363S/-1 R Head Amp. AH
IC6601 VHiBA7755//-1 R Head Switch AD
IC7701 RH-iX3057CEZZ R Servo/System Controller BA
IC7702 VHiBA6209//1E R Loading Motor Driver AG
TRANSISTORS
Q301 VS2SC2412KQ-1 R 2SC2412K AA
Q302 VSUN2213///-1 R UN2213 AA
Q303 VS2SC2412KQ-1 R 2SC2412K AA
Q471 VS2SA1037KQ-1 R 2SA1037K AA
Q472 VS2SA1266-Y-1 R 2SA1266(Y) AA
Q473 VS2SA1266-Y-1 R 2SA1266(Y) AA
Q474 VS2SA1266-Y-1 R 2SA1266(Y) AA
Q475 VS2SC2412KQ-1 R 2SC2412K AA
Q780 VS2SD1944K/-1 R 2SD1944K AE
Q781 VS2SD471-KL1E R 2SD471 AC
Q782 VSUN2213///-1 R UN2213 AA
Q783 VS2SB564-KL-1 R 2SB564 AC
Q801 VS2SA1266-Y-1 R 2SA1266(Y) AA
Q802 VS2SA1266-Y-1 R 2SA1266(Y) AA
Q803 VS2SA1266-Y-1 R 2SA1266(Y) AA
Q1001 VSUN2213///-1 R UN2213 AA
Q1002 VS2SB564-KL-1 R 2SB564 AC
Q1003 VSUN2213///-1 R UN2213 AA
Q1004 VS2SC2412KQ-1 R 2SC2412K AA
Q1005 VS2SC2412KQ-1 R 2SC2412K AA
Q1006 VS2SC2412KQ-1 R 2SC2412K AA
Q1007 VSUN2213///-1 R UN2213 AA
Q2206 VS2SA1037KQ-1 R 2SA1037K AA
Q2207 VS2SA1037KQ-1 R 2SA1037K AA
Q2208 VS2SC2412KQ-1 R 2SC2412K AA
Q2209 VS2SC2412KQ-1 R 2SC2412K AA
Q2210 VS2SC2412KQ-1 R 2SC2412K AA
Q2215 VS2SC2412KQ-1 R 2SC2412K AA
Q2217 VS2SC2412KQ-1 R 2SC2412K AA
Q2218 VSUN2113///-1 R UN2113 AA
Q2219 VSUN2213///-1 R UN2213 AA
Q2220 VS2SA1037KQ-1 R 2SA1037K AA
Q2224 VSUN2113///-1 R UN2113 AA
Q2227 VSUN2213///-1 R UN2213 AA
Q2233 VSUN2213///-1 R UN2213 AA
Q5504 VSUN2213///-1 R UN2213 AA
Q5507 VS2SC2412KQ-1 R 2SC2412K AA
Q6601 VSUN2213///-1 R UN2213 AA
Q6603 VS2C3939SQR-1 R 2C3939SQ AC
Q6604 VS2SC2001LK-1 R 2SC2001L AA
Q6605 VSUN2113///-1 R UN2113 AA
Q6606 VSUN2212///-1 R UN2212 AA
Q6607 VSUN2113///-1 R UN2113 AA
Q6608 VS2SC2412KQ-1 R 2SC2412K AA
Q6610 VSUN2213///-1 R UN2213 AA
Q7705 VS2SD1306-E-1 R 2SD1306 AC
Q7706 VS2SC2412KQ-1 R 2SC2412K AA
Q7711 VS2SC2412KQ-1 R 2SC2412K AA
Q7712 VS2SB1117KU1E R 2SB1117K AE
Q7720 VSUN2112///-1 R UN2112 AA
Q7721 VS2SC2412KQ-1 R 2SC2412K AA
Q7722 VS2SA1037KQ-1 R 2SA1037K AA
Q7723 VS2SB1117KU1E R 2SB1117K AE
Q7724 VS2SC3851A/-1 R 2SC3851A AD
Q7725 VS2SC2412KQ-1 R 2SC2412K AA
Q7851 VSUN2213///-1 R UN2213 AA
MODEL VT-G14
PWB-A DUNTK9568WEV0 – Main Unit —
PWB-B DUNTK9570WEV0 – TUNER/DEF Unit —
PWB-C DUNTK9569FMV0 – Power Unit —
PWB-D DUNTK9571WEV0 – CRT Unit —
PWB-E DUNTK9572WEV0 – FRONT AV Unit —
PWB-F DUNTK9576WEV0 – KEY Unit —
PWB-G DUNTK9573WEV0 – IF Unit —
MODEL VT-G21
PWB-A DUNTK9568WEV1 – Main Unit —
PWB-B DUNTK9570WEV1 – TUNER/DEF Unit —
PWB-C DUNTK9569WEV1 – Power Unit —
PWB-D DUNTK9571WEV1 – CRT Unit —
PWB-E DUNTK9572WEV0 – FRONT AV Unit —
PWB-F DUNTK9576WEV1 – KEY Unit —
PWB-G DUNTK9573WEV1 – IF Unit —
MODEL VT-G14
å V801 VB370BVBK1S-S R Picture Tube (14") BZ
å DY601 RCiLH0140PEZZ R Deflection Yoke BC
å L799 RCiLG0031PEZZ R Degaussing Coil AN
or
RCiLG0080PEZZ R Degaussing Coil AL
MODEL VT-G21
å V801 VB540ADAC1S*S R Picture Tube (21") CG
å DY601 RCiLH0146PEZZ R Deflection Yoke BF
å L799 RCiLG0025PEZZ R Degaussing Coil AW
or
RCiLG0069PEZZ R Degaussing Coil AR
