Sharp WH-236E - Remove of Breaker

15
Fig. 30
1. Remove the body in accordance with “REMOVE OF BODY”.
2. Remove split pin holding the breaker angle support to the breaker.
3. Remove 2 screws holding 2 breaker lead wires to the breaker.
4. Remove 2 screws holding the breaker to the back cover.
5. Now the breaker is free.
REMOVE OF BREAKER
Split pin
Breaker
Breaker lock
Back cover
Breaker angle support
Screw
Breaker lead wire
