6
The shower installation must be over 1.50 meters from the ground.
Fig. 7
3. Install electric water heater on wall.
Drill 2 holes in the wall with size 6 millimeters, 25 millimeters in depth, distant 178 millimeters
Put fitting in the holes.
Drive screws into the upper fitting and leave screws about 8-10 millimeters in length.
Hang the equipment with the screws and mark the lower points to drill the other 2 holes.
Drill 2 holes and put fittings, then drive all screws firmly.
Fig. 10
Screw
Fig. 8
2. Removing the body unit cover.
Remove the screw at the bottom of the unit.
Remove the front plate first at the bottom.
25 mm.
6 mm.
Fig. 9
Over 1.50 meters
178 mm.
