PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
XG-C335X
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] DUNTKD851WEF0 (MAIN Unit)
[3] DUNTKD868WEF0
(TERMINAL Unit)
[4] CABINET AND MECHANICAL
PARTS
[5] OPTICAL MECHANISM PARTS
[6] SUPPLIED ACCESSORIES
[7] PACKING PARTS
(NOT REPLACEMENT ITEM)
[8] SERVICE JIGS AND EQUIPMENT
(USE FOR SERVICING)
CONTENTS
LCD PROJECTOR
XG-C335X
MODEL
To Next Page
