Sharp XG-C335X User Manual

XG-C335X
4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[4] CABINET AND MECHANICAL PARTS
1 CBDYTA232WEF0 BX N J Top Body Ass'y
1-1 Not Available - - Top Body Ass'y
1-1-1 Not Available - - Top Body
1-1-2 HDECPA027WJSA AD J LED Cover
1-1-3 HiNDPB803WJSA AK J Operation Cover
1-1-4 PSPAZB308WJKZ AK J Heat Spacer
1-2 GCOVAB716WJKA AH J Lens Change Cover
1-3 GCOVAB780WJKA AE J Lens Upper Cover
1-4 LX-HZ3105CEFN AB J Screw for SW
1-5 PSPAT0010SEZZ AB J Tape
1-6 QCNW-D515WJQZ AG J Leaf Switch
1-7 XEBSN26P08000 AA J Screw, x2 (for Cover)
2 CBDYUA272WEF0 CB N J Bottom Body Ass'y
2-1 DCOVAB714WEF0 AU J Intake Cover Ass'y
2-1-1 Not Available - - Intake Cover
2-1-2 GLEGGA056WJKZ AC J Rear Leg
2-1-3 HPNC-A140WJSA AN J Intake Punching
2-1-4 PFiLDA022WJKZ AH J Intake Filter
2-2 CDAi-A300WEF0 BG J Adjuster Ass'y
2-2-1 Not Available - - Adjuster Stand
2-2-2 GCOVAB781WJKA AZ J Adjuster Cover
2-2-3 GLEGPA036WJSA AP J Adjuster, x2
2-2-4 JKNBKA004WJSA AD J Rotate Knob
2-2-5 LHLDSA001WJZZ AC J Shaft Holder, x2
2-2-6 LHLDZA779WJKZ AG J Gear Holder
2-2-7 NGERHA032WJZZ AD J Spur Gear
2-2-8 NSFTGA010WJFW AK J Gear Shaft
2-2-9 NSFTTA040WJFW AH J Rotate Shaft, x2
2-2-10 XEBSN30P08000 AA J Screw, x2 (for Adjuster)
2-2-11 XRESJ40-06000 AA J E-Ring For Shaft
2-3 Not Available - - Bottom Body Ass'y
2-3-1 Not Available - - Bottom Body
2-3-2 GCOVAB712WJSA AE J R/C Cover, x2
2-4 JHNDPA021WJKA AH J
Handle
2-5 LANGFA299WJFW AD J Antitheft Bracket, x2
2-6 LHLDZA773WJKA AG J Handle Holder, x2
2-7 LX-BZA067WJFN AB J Screw, x4 (for Angle)
2-8 LX-HZ3105CEFN AB J Screw for Leaf
2-9 LX-NZA003WJFW AD J Nut, x4
2-10 PFiLDA021WJKZ AE J Intake Filter Inlet
2-11 QCNW-E749WJQZ AN J Leaf SW
2-12 XEBSN26P08000 AA J Screw, x2
2-13 XEBSN30P12000 AA J Screw, x8
4 Not Available - - Lamp Door Ass'y
4-1 DCOVAB715WEF0 AM J Lamp Door Ass'y
4-1-1 Not Available - - Lamp Door
4-2 LX-BZ1009CEFN AE J For Lamp Door
4-3 MSPRC0023SEFW AB J Spring
4-4 XRESJ30-06000 AA J E-Ring
7 DUNTKD851WEF0 CR J MAIN Unit
8 DUNTKD868WEF0 BZ J TERMINAL Unit
9 DUNTKD874WEF0 AN J R/C Unit
10 DUNTKD869FMF0 BS J KEY Unit
11 DUNTKD870WEF0 BT J POWER Unit
12 DUNTKD871WEF0 AW J INLET Unit
13 DUNTKD875WEF0 BF J CONDENSER Unit
14 RDENCA179WJZZ CF J BALLAST Unit
15 LHLDFA011WJKZ AC J Ballast PWB Holder, x4
18 LX-BZ3100CEFN AA J Screw, x15
19 LX-BZA067WJFN AB J Screw For Earth
20 NFANRA065WJ00 BR J Power Unit Fan
21 PCAPHA026WJSA AP J Lens Cap
22 PSLDMB011WJFW AU J Power Shield
23 PSLDMB012WJFW AR J Ballast Shield
24 PSPAGA183WJKZ AC J Fan Spacer, x4
25 PSPAGA343WJKZ AQ J Speaker Holder
26 PZETKA195WJKZ AL J PW Bottom Insulator
27
PZETKA197WJKZ AE J PW Back Insul
28 PZETKA198WJKZ AT J Ballast Insulator
29 QCNW-E741WJPZ AU J Bimetal
30 QCNW-E744WJQZ AP J EA
31 QCNW-E745WJQZ AL J EB
33 RSP-ZA185WJQZ AN J Speaker
36 XEBSN30P12000 AA J Screws, C*1T*1P*3M*6B*9
37 Not Available - N - Serial No Label (XU)
37 Not Available - N - Serial No Label (XE)
37 Not Available - N - Serial No Label (XK)
38 LANGKA751WJFW AE J PWB Fitting Angle
39 PCOVUA093WJ00 AD J Light Shield
40 PCOVUA094WJ00 AF J Button Shield
41 PSLDMB010WJFW AH J Terminal Shield
43 XEBSN30P16000 AA J Screw, x2
