XG-C335X
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[5] OPTICAL MECHANISM PARTS
3 Not Available - - Optical Mechanism Unit
3-1 CHLDZA761WJ11 DY J Prism Holder Unit
3-1-1 MSPRPA089WJFW AR J PF Spring
3-1-2 PFiLWA119WJZZ CH J Gch Out Pre PF
3-1-3 PFiLWA118WJZZ CH J Gch Out Pre PF
3-1-4 PFiLWA107WJZZ CH J Gch OUT PF
3-1-5 MSPRPA089WJFW AR J PF Spring
3-1-6 PFiLWA114WJZZ CH J Bch Out Pre PF
3-1-7 PFiLWA109WJZZ CB J Bch OUT PF
3-1-8 PFiLWA116WJZZ CC J Bch Dummy Glass
3-1-9 MSPRPA088WJFW AR J PF Spring
3-1-10 PFiLWA115WJZZ CH J Rch Out Pre PF
3-1-11 PFiLWA105WJZZ CB J Rch OUT PF
3-1-12 XSPS920P02000 AB J Screw, x3
3-2 AN-C430LP - J Lamp Unit (Option)
3-3 CLNS-A077WJ01 CG J Projection Lens Ass'y
3-3-1 PCOVZA081WJSA AP J Zoom Ring
3-3-2 PCOVZA082WJSA AQ J Focus Ring
3-4 LANGKA773WJFW AL J G-In-Pf Adjt
3-5 LANGKA774WJFW AL J Sensor Mount
3-6 LANGKA863WJFW AM J Fuse Holder
3-7 LCHSKA023WJKZ BG J Unit Base
3-8 LHLDZA765WJKZ AG J Mirror Lever, x3
3-10 LX-BZA157WJF9 AF J Fan Screw, x4
3-11 MSPRPA079WJFW AF J Fly Pbs Spring, x2
3-12 MSPRPA080WJFW AH J Pbs Cl2 Spring
3-13 MSPRPA081WJFW AH J Mirror Fixing S, x7
3-14 MSPRPA086WJFW AH J Sld Spring, x4
3-15 NFANRA064WJ00 BC J Exhaust Fan
3-16 PCOVZA079WJKZ AY J Lamp House
3-17 CCOVZA080WJ01 BN J Unit Cover
3-18 PCOVZA086WJFW AT J Fan Guard
3-19 PDUC-A077WJKZ AN J Exhaust Duct
3-20 PFiLWA099WJZZ BL J
R IN PF
3-21 PFiLWA117WJZZ CB J G IN PRE-PF
3-22 PFiLWA101WJZZ BL J G IN PF
3-23 PFiLWA102WJZZ BL J B IN PRE-PF
3-24 PFiLWA103WJZZ BL J B IN PF
3-25 PFiLWA110WJZZ AW J RCH DF
3-26 PLNS-A069WJZZ BQ J Fly Lens 1 UV
3-27 PLNS-A070WJZZ BL J Fly Lens 2
3-28 PLNS-A072WJZZ AY J CL2
3-29 PLNS-A073WJZZ AT J CL 3 G-CH
3-30 PLNS-A074WJZZ AX J CL 4 R-CH-1, x2
3-31 PLNS-A075WJZZ AW J CL 5 R-CH-2
3-32 PLNS-A079WJZZ BE J CL3 B-CH
3-33 PMiR-A110WJZZ BF J M 1 DM B-REF
3-34 PMiR-A111WJZZ BA J M 2 DM G-REF
3-35 PMiR-A112WJZZ AP J M 3 AL R-REF, x2
3-36 PMiR-A113WJZZ AP J M 4 AL B-REF
3-37 PMiR-A114WJZZ BU J PBS
3-38 PSLDHA044WJFW AK J Heat Shield
3-39 PSLDPA063WJKZ AW J Shade Louver
3-40 PSLDPA066WJFW AK J Flyeye Aperture
3-41 PSLDPA067WJFW AH J Pbs Aperture
3-42 PSPAGA036WJZZ AE J Fan Spacer, x8
3-43 PSPAT0013CEZZ AC J Teflon Tape
3-44 QCNW-F127WJQZ BF J Temp Fuse
3-45 RH-HXA037WJQZ AU J Lcd Sensor
3-46 XBBSN30P08000 AA J Screw, x19
3-47 XBPS830P08JS0 AB J Screw, x6
3-48 XSPS920P02000 AB J Fuse Holder Screw
3-50 MSPRPA092WJFW AM J FLY PBS Spring 2
3-51 QCNW-F035WJQZ AR J GND Wire
5 Not Available - - Intake Duct Unit
5-1 PDUC-A070WJKZ AT J LCD Duct Upper
5-2 NFANSA023WJZZ BB J Blow Fan1
5-3
NFANSA024WJZZ BB J Blow Fan2
5-4 NFANSA025WJZZ BB J Blow Fan3
5-5 PDUC-A071WJKZ AU J LCD Duct Bottom
5-6 PSPAGA355WJZZ AB J Fan Spacer B
5-7 PSPAHA926WJZZ AB J LCD Fan Spacer, x6
5-8 RH-HXA036WJQZ AQ J Inlet Tmp Sensor
5-9 XEBSN30P12000 AA J Screw
6 Not Available - - Exhaust Duct Unit
6-1 PDUC-A074WJKZ AH J Blow Duct A
6-2 NFANSA023WJZZ BB J Blow Fan1
6-3 PDUC-A075WJKZ AL J Blow Duct B
6-4 PDUC-A076WJKZ AH J Blow Duct C
6-5 XEBSN30P10000 AA J For Blow Duct, x3
16 LHLDZA774WJKZ AH J Socket Holder
17 LHLDZA775WJKZ AH J Bimetal Holder
32 RH-HXA038WJQZ AT J Exhaust Temp. Sensor
35 XEBSN30P08000 AA J Screw for Bi-Metal
