NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PART CODE
PRICE
RANK
DESCRIPTION
XL-505H,505E,507E/CP-505,505E,507
R841 VRD-MN2BD102J J AA 1 kohm,1/8W
R842 VRD-MN2BD103J J AA 10 kohm,1/8W
R843 VRD-MN2BD473J J AA 47 kohms,1/8W
R844 VRD-MN2BD224J J AA 220 kohms,1/8W
R845 VRD-MN2BD225J J AA 2.2 Mohms,1/8W
R846 VRD-MN2BD333J J AA 33 kohms,1/8W
R852 VRD-MN2BD102J J AA 1 kohm,1/8W
R866 VRD-ST2EE820J J AA 82 ohms,1/4W
R867 VRD-ST2EE100J J AA 10 ohm,1/4W
R871,872 VRD-MN2BD103J J AA 10 kohm,1/8W
R873 VRD-ST2EE472J J AA 4.7 kohms,1/4W
R874 VRD-ST2EE103J J AA 10 kohm,1/4W
R875 VRD-MN2BD103J J AA 10 kohm,1/8W
R881 VRD-ST2EE221J J AA 220 ohms,1/4W
R885,886 VRD-MN2BD103J J AA 10 kohm,1/8W
R887,888 VRD-MN2BD152J J AA 1.5 kohms,1/8W [505E/507E]
R887,888 VRD-MN2BD182J J AA 1.8 kohms,1/8W [505H]
R901 VRD-ST2EE152J J AA 1.5 kohms,1/4W
R902 VRD-MN2BD563J J AA 56 kohms,1/8W
R903 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R904 VRD-MN2BD391J J AA 390 ohms,1/8W
R905 VRD-ST2EE103J J AA 10 kohm,1/4W
R906 VRD-ST2EE152J J AA 1.5 kohms,1/4W
R907 VRD-ST2EE103J J AA 10 kohm,1/4W
R908 VRD-MN2BD473J J AA 47 kohms,1/8W
OTHER CIRCUITRY PARTS
BI801/CNS801 QCNWN0975AWZZ J AH Connector Ass’y,8-8Pin
BI802/CNS802 QCNWN0976AWZZ J AF Connector Ass’y,7-7Pin
BI803/CNS803 QCNWN0977AWZZ J AG Connector Ass’y,6-6Pin
BI901/CNS901 QCNWN0973AWZZ J AG Connector Ass’y,7-7Pin
CNP101 92LCONE8P53253 J AC Plug,8Pin
CNP301 92LCONE-3P5268 J AC Plug,3Pin [ANTENNA]
CNP602 QCNCM010QAWZZ J AD Plug,15Pin
CNP603 QCNCM010NAWZZ J AC Plug,10Pin
CNP651 QCNCM038BAWZZ J AC Plug,2Pin
CNP803 92LCONE6P53254 J AC Plug,6Pin
CNP901 QCNCM932GAFZZ J AD Plug,7Pin
CNS101 QCNWN0341AWZZ J AL Connector Ass’y,8Pin
CNS602 QCNCW010QAWZZ J AE Socket,15Pin
CNS603 QCNCW010NAWZZ J AC Socket,10Pin
! F651 92LFUSET252E J AD Fuse,T2.5A,250V
! F652 92LFUSE-T122-E J AD Fuse,T1.25AL,250V
! F653 92LFUSET801E J AC Fuse,T800mA L 250V
FW601 QCNWN0974AWZZ J AD Flat Cable,5Pin
FW701 QCNWN0979AWZZ J AD Flat Cable,2Pin
FW702 QCNWN0978AWZZ J AD Flat Cable,2Pin
FW901 QCNWN0342AWZZ J AC Flat Cable,2Pin
J601 QJAKM0007AWZZ J AF Jack,Headphones
LCD701 RV-LX0027AWZZ J AP LCD
M801 92LMTR1854BASY J AP Motor with Gear [Sled]
M802 92LMTR1906CASY J AS Motor with Chassis [Spindle]
M901 92LMTR2538AASY J AS Motor with Pulley [TAPE]
RX701 VHL21043TE2-1 J AL Remote Sensor,21043TE2
SO601 QTANA0404AWZZ J AF Terminal,Speaker
! SO651 QSOCA0204AWZZ J AF Socket,AC Input
SOL901 RPLU-0002AWZZ J AH Solenoid
SW701 QSW-P0004AWZZ J AE Switch,Push Type [CD EJECT]
SW702 QSW-K0004AWZZ J AC Switch,Key Type
[PLAY/CD PAUSE/TUNING
UP]
SW703 QSW-K0004AWZZ J AC Switch,Key Type
[VOLUME DOWN]
SW704 QSW-K0004AWZZ J AC Switch,Key Type [VOLUME UP]
SW705 QSW-K0004AWZZ J AC Switch,Key Type
[X-BASS/EQUALIZER]
SW706 QSW-K0004AWZZ J AC Switch,Key Type [BAND]
SW707 QSW-K0004AWZZ J AC Switch,Key Type [FUNCTION]
SW710 QSW-K0004AWZZ J AC Switch,Key Type [REC.PAUSE]
SW711 QSW-K0004AWZZ J AC Switch,Key Type
[MEMORY/SET]
SW712 QSW-K0004AWZZ J AC Switch,Key Type
[PRESET DOWN]
SW713 QSW-K0004AWZZ J AC Switch,Key Type [PRESET UP]
SW714 QSW-K0004AWZZ J AC Switch,Key Type [STOP/CLEAR]
SW718 QSW-K0004AWZZ J AC Switch,Key Type
[ON/STAND-BY]
SW801 QSW-F9001AWZZ J AE Switch,Leaf Type [Pickup In]
SW901 92LM-1676A J AC Switch,Leaf Type
[Record Prevention]
SW902 92LM-1658A J AB Switch,Leaf Type [Cam]
TP801 92LCONE-3P5267 J AB Plug,3Pin [Test Point]
CASSETTE MECHANISM PARTS
101 LCHSM0015AW01 J AK Main Chassis Ass’y
102 LPLTP0002AWZZ J AD Plate,Head
103 NDAIR0005AW01 J AG Take Up Reel Ass’y
104 NGERH0024AWZZ J AB Gear,Supply Reel
105 NROLY0002AWZZ J AF Pinch Roller Ass’y
106 NFLYC0002AWZZ J AG Flywheel Ass’y
107 MLEVP0024AW01 J AH Lever,FR Ass’y
108 NGERH0027AWZZ J AE Gear,Cam
109 NGERH0028AWZZ J AB Gear,Flywheel
110 NGERH0030AWZZ J AE Gear,Play Idler
111 NGERH0032AWZZ J AC Gear,FF
112 NPLYB0004AWZZ J AB Sensor,Wing
113 MLEVP0026AWZZ J AC Lever,Trigger
114 92LM-LEV1756A J AB Lever,Lock
115 MLEVP0069AWZZ J AB Lever,Eject Obstruct
116 LHLDS1001AW01 J AE Hold Bearing Ass’y
117 PGIDM0008AWZZ J AC Guide,Cassette
118 MLEVF0008AW01 J AD Lever,Idler Ass’y
119 MLEVF0009AW01 J AE Lever,Over Strok Ass’y
120 LANGT0026AWFW J AC Blacket,Hold
121 LANGT0027AWFW J AD Blacket,Motor
122 LANGT0033AWFW J AB Blacket,Switch
123 MSPRP0005AWFW J AB Spring,Cassette
124 MSPRC0008AWFJ J AB Spring,Back Tention
126 MSPRC0025AWFJ J AB Spring,Supply Cap
127 92LM-TSPR1756C J AB Spring,Lock Lever
128 MSPRD0033AWFJ J AB Spring,Play Idler Lever
129 MSPRD0034AWFJ J AB Spring,Play Roller
130 MSPRD0036AWFJ J AB Spring,Play Return
131 MSPRD0037AWFJ J AB Spring,Over Strok Lever
132 MSPRD0039AWFJ J AB Spring,FR Lever
133 MSPRD0040AWFJ J AB Spring,Eject Obstruct
134 NBLTK0030AWZZ J AC Belt,Sub
135 NBLTK0010AWZZ J AC Belt,Main
136 MSPRD0045AWFJ J AB Spring,Trigger Lever
137 RHEDH0002AWZZ J AM Head,Record/Playback
138 RHEDB0001AWZZ J AG Head,Erase
139 92LN-BAND1318A J AA Nylon Band,80mm
141 92LM-REL1676B J AB Cap,Supply Reel
501 92L1R8WC4-R5P J AA Washer,ø1.8×ø4×0.5mm
502 92L1R5WC3R8R5P J AA Washer,ø1.5×ø3.8×0.5mm
503 92L2TTS+4BZ J AA Screw,ø2×4mm
504 92L2TTS+5BZ J AA Screw,ø2×5mm
505 92LS2R6S1746A J AA Screw,ø2.6×5mm
506 92L2R3W3R4R25P J AA Washer,ø2.3×ø3.4×0.25mm
507 92L2R2TWO J AA Washer,ø2.2mm
508 LX-BZ0004AWFD J AC Screw,ø2.6mm Lock Lever
509 XHPSD20P05000 J AA Screw,ø2×5mm
M901 92LMTR2538AASY J AS Motor with Pulley [TAPE]
SOL901 RPLU-0002AWZZ J AH Solenoid Ass’y
SW901 92LM-SW1676A J AC Switch,Leaf Type [Record
Prevention]
SW902 92LM-SW1658A J AB Switch,Leaf Type [Cam]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0010AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 92LM-CUSN1524A J AC Cushion,Gum
! 306 92LHPC-1MX J BF Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
307 PCOVP1001AWSA J AE Cover,Mechanism
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
M801 92LMTR1854BASY J AP Motor with Gear [Sled]
M802 92LMTR1906CASY J AS Motor with Chassis [Spindle]
SW801 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
CABINET PARTS
201 92LCAB2538AS1 J AT Front Panel Ass’y [505H/505E]
– 4 –
