XL-505H,505E,507E/CP-505,505E,507
201 92LCAB2539AS1 J AU Front Panel Ass’y [507E]
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 92LBADGE1692A J AC Badge,SHARP
201- 3 HDECQ0219AWSA J AG Panel,LCD
201- 4 GCOVH1010AWSA J AC Cover,Remote Control Sensor
202 LANGT0042AWFW J AC Bracket,PWB Support
203 92LCUSN1746A J AA Cushion,Leg
204 JKNBZ0382AWSA J AG Knob,Operation
204 LCHSM0058AWFW J AM Main Chassis
205 MLIFP0003AWZZ J AE Damper,Cassette Holder
206 MSPRD0093AWFJ J AB Spring,Cassette Holder
207 92LPNL2538AS1 J AM Cassette Holder Ass’y
207- 1 ———— — Cassette Holder
(Not Replacement Item)
207- 2 HDECQ0223AWSA J AF Panel,Cassette Holder
[505H/505E]
207- 2 HDECQ0252AWSA J AF Panel,Cassette Holder [507E]
209 92LN-BAND1318A J AA Nylon Band,80mm
210 PCOVW1005AWZZ J AD Cover,PWB
211 92LCAUT1706A1 J AC Label,Class-3A Laser
212 92LCAUT1706B J AA Label,Laser
213 GCABB1164AWSA J AH Rear Panel
214 GITAS0037AWSA J AH Side Panel,Left
215 GITAS0038AWSA J AH Side Panel,Right
216 GCABC1164AWSA J AL Top Cabinet
217 PCOVS3020AWFW J AE Shield,Main PWB
218 GDORT0012AWSA J AG CD Lid
219 JKNBZ0128AWSB J AC Knob,CD Eject
220 92LLEV1651A J AB Lever,CD Eject Knob
221 MLIFP0003AWZZ J AE Damper,CD Lid
222 MSPRD0098AWFJ J AD Spring,CD Lid
223 92LMAG2538AS1 J AL Stabilizer Ass’y
223- 1 ———— — Stabilizer
(Not Replacement Item)
223- 2 92LCUSN1651A J AC Cushion,Stabilizer
223- 3 PMAGF0002AWZZ J AE Magnet
224 PRDAR0081AWFW J AK Heat Sink
225 LHLDZ1155AWZZ J AE Holder,LCD
226 LHLDZ1157AWZZ J AD Holder,LED
227 PSHEP0016AWZZ J AD Sheet,LCD
228 TLABS0136AWZZ J AB Caution Label,East Europe
[505H Only]
229 TSPC-0448AWZZ1 J Label,Specifications [505H]
229 TSPC-0451AWZZ J AE Label,Specifications
[505E For UK]
229 TSPC-0453AWZZ J AE Label,Specifications [507E]
229 TSPC-0455AWZZ J AE Label,Specifications
[505E For Europe]
230 QFSHD0001AWZZ J AB Holder,Fuse
601 LX-JZ0010AFFD J AA Screw,ø3×10mm
602 XESSD30P10000 J AA Screw,ø3×10mm
603 XHBSD40P06000 J AA Screw,ø4×6mm
604 XEBSD30P10000 J AA Screw,ø3×10mm
605 XJBSD30P10000 J AA Screw,ø3×10mm
606 XESSF30P12000 J AA Screw,ø3×12mm
607 XJBSF30P10000 J AA Screw,ø3×10mm
608 LX-EZ0005AWFD J AA Screw,Special
610 XJBSD30P08000 J AA Screw,ø3×8mm
611 XJBSD30P06000 J AA Screw,ø3×6mm
612 XEBSF30P08000 J AA Screw,ø3×8mm
ACCESSORIES/PACKING PARTS
1 QANTL0004AWZZ J AG FM/AM Loop Antenna
2 SPAKA0144AWZZ J AL Packing Add.
3 SPAKC0538AWZZ J AP Packing Case [505H]
3 SPAKC0553AWZZ J AP Packing Case [507E]
3 SPAKC0558AWZZ J AN Packing Case [505E]
4 SSAKH0014AWZZ J AB Polyethylene Bag,Unit
5 TINSE0176AWZZ J AR Operation Manual
[505E For UK/507E]
5 TINSZ0233AWZZ J AP Operation Manual
[505H/505E For Europe]
6 TLABE0180AWZZ J AB Label,Bar Code [505H]
6 TLABE0185AWZZ J AB Label,Bar Code [507E]
6 TLABE0186AWZZ J AB Label,Bar Code [505E]
7 TLABM0038AWZZ J AC Label,Feature
8 92LBAG1460C1 J AB Polyethylene Bag,Accessories
9 92LBAG1658B J AA Polyethylene Bag,AC Power
Supply Cord
! 10 QACCB0004AW00 J BB AC Power Supply Cord
[505E For UK/507E]
! 10 QACCE0007AW00 J AR AC Power Supply Cord
[505H/505E For Europe]
11 92LCARD1751A J AB Card,Registration
[505E For UK/507E Only]
12 RRMCG0106AWSA J AX Remote Control
12- 1 GFTAB1017AWSA J Lid,Remote Control
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1~7 92LPWB2538MANS J — Main/CD Servo/Display/LED/
Headphones/Power Supply/CD
Lid Switch (Combined Ass'y)
[505E For UK/507E Only]
PWB-B QPWBF0027AWZZ J AD CD Motor (PWB Only)
[505E For UK/507E Only]
PWB-C QPWBF0107AWZZ J AD Tape Mechanism (PWB Only)
[505E For UK/507E Only]
SPEAKER BOX PARTS
701 92L121-0098 J AS Net Frame Ass’y
702 92L051-0030 J AV Speaker Box,Wooden [CP-505]
702 92L051-0031 J AU Speaker Box,Wooden [CP-505E]
702 92L051-0035 J AW Speaker Box,Wooden [CP-507]
704 92L372-0049 J AB Screw,ø4×12mm
705 92L291-0007 J AF Speaker Cord
706 92L351-0194 J Label,Specifications [CP-505E]
706 92L351-0195 J Label,Specifications [CP-505]
706 92L351-0196 J Label,Specifications [CP-507]
SP1,2 VSP0010PBT24A J AU Woofer
PACKING PARTS
1 SPAKA0143AWZZ J Packing Add.,Speaker
2 92L411-0019 J AB Polyethylene Bag,Speaker
