Sharp XL-570 - CD Control Section

XL-560,570/C
– 4 –
CP-XL570U
XL-560,570/C
1
2
3
4
1
2
3
4
Illustration: XL-560/570
CP-XL560U
■ Speaker section
1. Tweeter
2. Woofer
3. Bass Reflex Ducts
4. Speaker Wire
1. Tweeter
2. Woofer
3. Speaker Terminals
4. Bass Reflex Ducts
■ Remote control
1. Remote Control Transmitter LED
● Tuner control section
2. Preset Up/Down Buttons
● CD control section
3. Clear Button
4. Random/Repeat Button
5. Memory Button
6. Stop Button
7. Play/Pause Button
8. Track Down/Review Button
● Tape control section
10. Record Pause/Beat Cancel Selector
Button
11. Rewind Button
12. Stop Button
13. Play Button
14. Fast Forward Button
● Common section
15. Sleep Button
16. Bass Up/Down Buttons
17. Function Selector Buttons
18. Power Button
19. Timer Button
20. Clock Button
21. Treble Up/Down Buttons
22. Volume Up/Down Buttons
9. Track Up/Cue Button
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
