Sharp XR-32S-L Service Manual

XR-32S-L/XR-32X-L/PG-F212X-L
16
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R3825 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R3826 VRS-CY1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R3827 VRS-CY1JF271FY AA J Resistor 270 1/16W Metal Oxide
R3828 VRS-CY1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R3829 VRS-CY1JF152FY AA J Resistor 1.5k 1/16W Metal Oxide
R3830 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3831 VRS-TV1JD000JY AA J Resistor 0 1/16W Metal Oxide
R3832 VRS-CY1JF222FY AA J Resistor 2.2k 1/16W Metal Oxide
R3834 VRS-TV1JD000JY AA J Resistor 0 1/16W Metal Oxide
R3835 VRS-TW2HF2R7JY AA J Resistor 2.7 1/2W Metal Oxide
R3837 VRS-TQ2EDR47FY AC J Resistor 0.47 1/4W Metal Oxide
R3838 VRS-CY1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R3839 VRS-TW2ED000JY AB J Resistor 0 1/4W Metal Oxide
R3841 VRS-CY1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R3842 VRS-CY1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R3843 VRS-CY1JF151JY AA J Resistor 150 1/16W Metal Oxide
R3846 VRS-CY1JF151JY AA J Resistor 150 1/16W Metal Oxide
R3848 VRS-CY1JF151JY AA J Resistor 150 1/16W Metal Oxide
R3849 VRS-TV1JD000JY AA J Resistor 0 1/16W Metal Oxide
R3857 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3858 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3859 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3867 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R3868 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R3869 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R3870 VRS-TW2ED000JY AB J Resistor 0 1/4W Metal Oxide
R3872 VRS-CY1JF392DY AA J Resistor 3.9k 1/16W Metal Oxide
R3873 VRS-CY1JF180JY AA J Resistor 18 1/16W Metal Oxide
R3874 VRS-CY1JF272DY AA J Resistor 2.7k 1/16W Metal Oxide
R3875 VRS-CY1JF100JY AA J Resistor 10 1/16W Metal Oxide
R3876 VRS-CY1JF272DY AA J Resistor 2.7k 1/16W Metal Oxide
R3877 VRS-CY1JF102DY AA J Resistor 1k 1/16W Metal Oxide
R3878 VRS-CY1JF100JY AA J Resistor 10 1/16W Metal Oxide
R3879 VRS-CY1JF272DY AA J
Resistor 2.7k 1/16W Metal Oxide
R3880 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R3881 VRS-TQ2BD1R0JY AA J Resistor 1 1/8W Metal Oxide
R3882 VRS-TQ2BD1R0JY AA J Resistor 1 1/8W Metal Oxide
R3883 VRS-TQ2BD1R0JY AA J Resistor 1 1/8W Metal Oxide
R3884 VRS-TW2HF2R7JY AA J Resistor 2.7 1/2W Metal Oxide
R3885 VRS-TW2HPR20JY AB J Resistor 0.2 1/2W Metal Oxide
R3886 VRS-TW2HPR20JY AB J Resistor 0.2 1/2W Metal Oxide
R3887 VRS-TV1JD000JY AA J Resistor 0 1/16W Metal Oxide
R3888 VRS-TV1JD000JY AA J Resistor 0 1/16W Metal Oxide
S2001 QSW-SA020WJZZY AE J Switch
S2551 QSW-K0099TAZZY AC J Switch (SERVICE)
S2552 QSW-KA029WJZZY AD J Switch (POWER)
S2553 QSW-KA029WJZZY AD J Switch (-)
S2554 QSW-KA029WJZZY AD J Switch (DOWN)
S2555 QSW-KA029WJZZY AD J Switch (UP)
S2556 QSW-KA029WJZZY AD J Switch (ENTER)
S2557 QSW-KA029WJZZY AD J Switch (+)
S2558 QSW-KA029WJZZY AD J Switch (MENU)
S2559 QSW-KA029WJZZY AD J Switch (KEYSTONE)
S2560 QSW-KA029WJZZY AD J Switch (ECO/QUIET)
SC2551 QSOCDA036WJZZ AF J Socket 12Pin
SC2801 QSOCZA061WJZZ AK J Socket (PG-F212X-L)
SC2801 QSOCNA423WJPZ AK J Socket (XR-32X-L)
SC3051 QSOCNA230WJZZ AH J Socket 17Pin (INPUT)
SC3101 QSOCNA229WJZZ AH J Socket 17Pin (OUTPUT)
SC3801 QCNCWA500WJZZY AC J Connector 4Pin (MO)
TH3501 VHH103KT161-1Y AE J Thermistor
X2201 RCRSCA180WJQZY AL J Crystal
X3351 RCRSC0170TAZZY AG J Crystal 14.31818MHz
N LHLDW1226CEZZ AC J Holder
N LX-BZ3100CEF7 AA J Screw, x2
N NSFTZA261WJFW AC J Shaft , x2(XR-32X-L/PG-F212X-L)
N PCOVUA105WJ00 AF J Cover
N
PSLDMB281WJFW AH J Shield
N PSLDMB313WJFW AH N J Main PWB Shield (PG-F212X-L)
N PSLDMB385WJZZ AK N J Shield (XR-32S-L/XR-32X-L)
[3] DUNTKE391WEF0 (DMD Unit)
C9301 RC-KZA514WJZZY AF J Capacitor 3.3 50V Ceramic
C9302 RC-KZA514WJZZY AF J Capacitor 3.3 50V Ceramic
C9303 RC-KZA109WJZZY AC J Capacitor 10 16V Ceramic
C9304 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C9305 VCEAPF1CW106MY AB J Capacitor 10 16V Electrolytic
C9306 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C9307 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C9308 VCEAPF1CW106MY AB J Capacitor 10 16V Electrolytic
C9309 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C9310 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C9311 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C9312 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C9313 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
[2] DUNTKE390FMG4/5/6 (MAIN Unit)
