Sharp XR-32S-L Service Manual

XR-32S-L/XR-32X-L/PG-F212X-L
17
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
C9314 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C9315 RC-KZ0072TAZZY AC J Capacitor 1 25V Electrolytic
C9316 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C9317 RC-KZ0070TAZZY AD J Capacitor 4.7 16V Electrolytic
C9318 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C9319 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C9320 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C9321 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C9322 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C9501 RC-KZA066WJZZY AB J Capacitor 1 25V Electrolytic
C9502 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C9503 VCKYCY1HF104ZY AA J Capacitor 0.1 50V Ceramic
C9504 RC-KZA066WJZZY AB J Capacitor 1 25V Electrolytic
C9505 VCKYCY1HF104ZY AA J Capacitor 0.1 50V Ceramic
C9506 VCKYCY1HF104ZY AA J Capacitor 0.1 50V Ceramic
C9507 VCKYCY1HF104ZY AA J Capacitor 0.1 50V Ceramic
C9508 VCKYCY1HF104ZY AA J Capacitor 0.1 50V Ceramic
C9509 VCKYCY1HF104ZY AA J Capacitor 0.1 50V Ceramic
C9510 VCKYCY1HF104ZY AA J Capacitor 0.1 50V Ceramic
C9511 VCKYCY1HF104ZY AA J Capacitor 0.1 50V Ceramic
C9512 VCKYCY1HF104ZY AA J Capacitor 0.1 50V Ceramic
C9513 VCKYCY1HF104ZY AA J Capacitor 0.1 50V Ceramic
C9514 VCKYCY1HF104ZY AA J Capacitor 0.1 50V Ceramic
C9515 VCKYCY1HF104ZY AA J Capacitor 0.1 50V Ceramic
C9516 VCKYCY1HF104ZY AA J Capacitor 0.1 50V Ceramic
C9517 VCEAPF1CW106MY AB J Capacitor 10 16V Electrolytic
C9518 VCEAPF1CW106MY AB J Capacitor 10 16V Electrolytic
D9301 VHDSJPBL6++-1Y AD J Diode SJPB-L6VL
D9302 VHDSJPBL6++-1Y AD J Diode SJPB-L6VL
D9304 RH-EX1009GEZZY AE J Zener Diode PTZTE259.1B
FB9301 RBLN-A191WJZZY AB J Ferrite Bead
FB9302 RBLN-A191WJZZY AB J Ferrite Bead
FB9303 RBLN-A191WJZZY AB J Ferrite Bead
FB9501 RBLN-A191WJZZY AB J
Ferrite Bead
IC9301 RH-iXC119WJZZQ CA J IC 2506593-0004
L9301 RCiLP0325TAZZY AD J Coil
L9302 RCiLP0325TAZZY AD J Coil
R9301 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R9303 VRS-CJ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R9304 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R9305 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R9306 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R9501 VRS-CY1JF330JY AA J Resistor 33 1/16W Metal Oxide
R9504 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R9505 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R9506 VRS-CY1JF100JY AA J Resistor 10 1/16W Metal Oxide
R9507 VRS-CY1JF100JY AA J Resistor 10 1/16W Metal Oxide
SC9101 QSOCZA140WJZZQ AZ J Socket 122Pin
SC9501 QSOCZA127WJZZQ AS J Socket
[4] DUNTKE392WEF3 (BALLAST POWER Unit)
C701 RC-KZA111WJZZY AC J Capacitor 1 25V Electrolytic
!
C702 RC-FZA026WJZZ AE J Capacitor 0.47 275V
!
C703 RC-KZA551WJZZ AD J Capacitor 2200p 250V Electrolytic
!
C704 RC-KZA551WJZZ AD J Capacitor 2200p 250V Electrolytic
!
C705 RC-FZA026WJZZ AE J Capacitor 0.47 275V
!
C706 RC-KZA551WJZZ AD J Capacitor 2200p 250V Electrolytic
C707 RC-KZA437WJZZY AD J Capacitor 1000p 630V Electrolytic
C708 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C709 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C710 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C711 RC-EZB527WJZZ AG J Capacitor 2200 10V Electrolytic
C712 RC-FZ0010TAZZ AC J Capacitor 0.01 630V
C714 RC-EZA490WJZZ+ AD J Capacitor 100 35V Electrolytic
C715 VCKYCY1HB102KY AA J Capacitor 1000p 50V Ceramic
C716 RC-FZA126WJZZ AE J Capacitor 0.1 450V
C717 VCKYTV1EB474KY AC J Capacitor 0.47 25V Ceramic
C718 VCEA4A1HN475M+ AC J Capacitor 4.7 50V Electrolytic
C720 VCKYCY1HB473KY AA J Capacitor 0.047 50V Ceramic
C721 RC-KZA296WJZZ AE J Capacitor 100p 2kV Electrolytic
C722 VCKYTQ1HB104KY AD J Capacitor 0.1 50V Ceramic
C723 VCKYTV1HB471KY AA J Capacitor 470p 50V Ceramic
C724 VCKYTV1HB104KY AA J Capacitor 0.1 50V Ceramic
C727 RC-KZA437WJZZY AD J Capacitor 1000p 630V Electrolytic
C728 RC-EZB528WJZZ AL J Capacitor 2200 250V Electrolytic
C730 VCKYTV1EB104KY AB J Capacitor 0.1 25V Ceramic
!
C731 RC-KZA551WJZZ AD J Capacitor 2200p 250V Electrolytic
!
C732 RC-KZA551WJZZ AD J Capacitor 2200p 250V Electrolytic
C733 VCKYCY1HB472KY AA J Capacitor 4700p 50V Ceramic
C734 VCKYTQ1HB224KY AC J Capacitor 0.22 50V Ceramic
C735 VCKYCY1HB332KY AA J Capacitor 3300p 50V Ceramic
C736 RC-FZA215WJZZ AH J Capacitor 1.8 450V
C737 RC-EZA490WJZZ+ AD J Capacitor 100 35V Electrolytic
C738 VCEA4A1VN476M+ AC J Capacitor 47 35V Electrolytic
[3] DUNTKE391WEF0 (DMD Unit)
