Sharp XR-32S-L Service Manual

XR-32S-L/XR-32X-L/PG-F212X-L
18
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
C739 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C740 RC-EZB574WJZZ AT N J Capacitor 270 450V Electrolytic
C743 VCKYCY1HB104KY AA J Capacitor 0.1 50V Ceramic
C744 VCEA4A1VN476M+ AC J Capacitor 47 35V Electrolytic
C745 RC-KZA304WJZZ AD J Capacitor 470p 2kV Electrolytic
C747 RC-KZA304WJZZ AD J Capacitor 470p 2kV Electrolytic
C748 RC-KZA110WJZZY AD J Capacitor 10 Electrolytic
C751 RC-KZA215WJZZY AC J Capacitor 1 50V Ceramic
C901 RC-FZA123WJZZ AF J Capacitor 1 450V
C903 VCKYCY1EB473KY AA J Capacitor 0.047 25V Ceramic
C904 RC-KZA111WJZZY AC J Capacitor 1 25V Electrolytic
C905 RC-KZA448WJZZY AD J Capacitor 220p 1kV Electrolytic
C907 RC-KZA448WJZZY AD J Capacitor 220p 1kV Electrolytic
C908 RC-KZA449WJZZY AD J Capacitor 330p 1kV Electrolytic
C909 RC-KZA449WJZZY AD J Capacitor 330p 1kV Electrolytic
C911 RC-KZA275WJZZ AD J Capacitor 1000p 2kV Electrolytic
C912 RC-FZA123WJZZ AF J Capacitor 1 450V
C913 RC-KZA437WJZZY AD J Capacitor 1000p 630V Electrolytic
C915 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C917 RC-FZA126WJZZ AE J Capacitor 0.1 450V
C919 RC-FZA296WJZZ AG J Capacitor 0.047 450V
C920 RC-KZA275WJZZ AD J Capacitor 1000p 2kV Electrolytic
C921 VCKYCY1HB103KY AA J Capacitor 0.01 50V Ceramic
C922 RC-KZA275WJZZ AD J Capacitor 1000p 2kV Electrolytic
C923 RC-KZA449WJZZY AD J Capacitor 330p 1kV Electrolytic
C924 RC-KZA449WJZZY AD J Capacitor 330p 1kV Electrolytic
!
CN901 QCNW-H946WJQZ BB N J Connecting Cord
!
D701 RH-FXA003WJZZ AD J Diode PC123Y82
!
D702 VHDD10XB60H-1 AL J Diode D10XB60H-7101
D703 VHDSBT8006J-1 AH J Diode SBT80-06J
D704 VHDBAS316//-1Y AB J Diode BAS316,115
D706 RH-DXA070WJZZY AE J Diode SARS01V1
D708 VHDD1FL20U/-1Y AC J Diode D1FL20U-5053
!
D711 RH-FXA003WJZZ AD J Diode PC123Y82
D714 VHDLi114+++-1Y AC J Diode LI114
D716 VHDSBT8010J-1 AH J Diode SBT80-10J
D717 VHDBAS316//-1Y AB J Diode BAS316,115
D718 VHDRB160M40-1Y AC J Diode RB160M-40TR
D719 VHDRB160M40-1Y AC J Diode RB160M-40TR
D720 VHDRD1006LS-1 AG N J Diode RD1006LS-SB5
D722 RH-EX1015GEZZY AD J Zener Diode PTZTE2516B
D723 RH-EXA359WJZZY AE J Zener Diode PTZTE2533B
D724 VHDCRF03T5L-1Y AF J Diode CRF03(T5L,SHARP,Q)
D725 VHDCRF03T5L-1Y AF J Diode CRF03(T5L,SHARP,Q)
D726 RH-EX1262CEZZY AB J Diode HZU9.1B2TRF
D902 VHDRB160M40-1Y AC J Diode RB160M-40TR
D903 VHDRD1006LS-1 AG N J Diode RD1006LS-SB5
D904 VHDCRF03T5L-1Y AF J Diode CRF03(T5L,SHARP,Q)
D905 VHSG1VL22C+-1Y AP J Diode SI.Control Rectifier
D906 RH-DXA062WJZZY AE J Diode SHV-04V6
D907 VHDFMVG2GS+-1 AM J Diode FMV-G2GS
D910 RH-DXA062WJZZY AE J Diode SHV-04V6
E701 LANGQA041WJFW AG J Fixing Metal
!
F701 QFS-DA036WJZZ AE N J Fuse 6.3A AC250V
!
F703 QFS-TA005WJZZ AG J Fuse TA005WJ 127°C
!
F704 QFS-ZA052WJZZ AT J Fuse 2A D450V
!
F705 QFS-ZA054WJZZ AG J Fuse 3.15A DC450V
FB701 RBLN-A007WJZZY AC J Ferrite Bead
FB702 RBLN-A007WJZZY AC J Ferrite Bead
FB703 RBLN-0020CEZZ+ AB J Ferrite Bead
FB704 RBLN-A007WJZZY AC J Ferrite Bead
FB707 RBLN-0020CEZZ+ AB J Ferrite Bead
FB711 RBLN-0020CEZZ+ AB J Ferrite Bead
FB712 RBLN-A007WJZZY AC J Ferrite Bead
FB713 RBLN-0020CEZZ+ AB J Ferrite Bead
FB901 RBLN-A007WJZZY AC J Ferrite Bead
FH701 QFSHD1017CEZZ+ AC J Fuse Holder
FH702 QFSHD1018CEZZ+ AC J Fuse Holder
IC702 VHiTA78L12F-1Y AF J IC TA78L12F(TE12L,F)
IC704 VHiSTRY6473-1 AK J IC STR-Y6473LFNo.3001
IC705 VHiTA76431R1EY AB N J IC TA76431FR(T2LSHR,F
IC707 VHiFA5551N+-1Y AH J IC FA5551N-D1-TE1
!
L701 RCiLFA178WJZZ AK J Coil
!
L702 RCiLFA178WJZZ AK J Coil
L703 RCiLPA546WJZZ AH J Coil
L704 RCiLCA126WJZZ AQ J Coil
L901 RCiLPA137WJZZ AF J Coil
L903 RCiLPA546WJZZ AH J Coil
L904 RCiLCA126WJZZ AQ J Coil
LUG701 QLUGHA002WJZZ AB J Lug
LUG702 QLUGHA002WJZZ AB J Lug
!
P701 QPLGAA007WJZZ AM J Plug 3Pin
!
P702 QPLGN0269GEZZ AB J Plug 2Pin
P704 QCNCMA114WJZZ AF J Plug 14Pin
[4] DUNTKE392WEF3 (BALLAST POWER Unit)
