Sharp XR-32S-L Service Manual

XR-32S-L/XR-32X-L/PG-F212X-L
19
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
Q701 VS2SA1797Q+-1Y AD J Transistor 2SA1797 T100Q
Q704 VS2SK4087LS1E AL N J Transistor 2SK4087LS-CGC11
Q705 VS2SK4087LS1E AL N J Transistor 2SK4087LS-CGC11
Q706 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q707 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q708 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q709 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q901 VS2SK4087LS1E AL N J Transistor 2SK4087LS-CGC11
Q903 VS2SA2056++-1Y AE J Transistor 2SA2056(TE85L,F)
Q904 VSF5E52VX3+-1Y AG J Transistor F5E52VX3-7061
Q905 VS2SA1530AR-1Y AB J Transistor 2SA1530A-T112-1R
Q906 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
R701 VRS-TQ2BD103JY AA J Resistor 10k 1/8W Metal Oxide
R702 VRS-TV1JD564JY AA J Resistor 560k 1/16W Metal Oxide
R703 VRS-TV1JD564JY AA J Resistor 560k 1/16W Metal Oxide
R704 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R708 VRS-VV3DB220J AA J Resistor 22 2W Metal Oxide
R709 VRS-VV3AB104J AB J Resistor 100k 1W Metal Oxide
R710 VRS-VV3AB104J AB J Resistor 100k 1W Metal Oxide
R712 VRS-TV1JD473JY AB J Resistor 47k 1/16W Metal Oxide
R714 VRS-TV1JD473JY AB J Resistor 47k 1/16W Metal Oxide
R715 VRS-TQ2BD101JY AA J Resistor 100 1/8W Metal Oxide
R716 VRN-VV3DBR47J AB J Resistor 0.47 2W Metal Film
R717 VRS-CY1JF103FY AA J Resistor 10k 1/16W Metal Oxide
R718 VRS-TV1JD153JY AA J Resistor 15k 1/16W Metal Oxide
R719 VRS-TQ2BD334FY AA N J Resistor 330k 1/8W Metal Oxide
R722 VRS-TQ2BD000JY AA J Resistor 0 1/8W Metal Oxide
R723 VRS-CY1JF222DY AA J Resistor 2.2k 1/16W Metal Oxide
R724 VRS-TQ2BD102JY AA J Resistor 1k 1/8W Metal Oxide
R725 VRS-CY1JF101FY AA J Resistor 100 1/16W Metal Oxide
R726 VRS-TQ2EF122JY AA J Resistor 1.2k 1/4W Metal Oxide
R727 VRS-CY1JF912DY AB J Resistor 9.1k 1/16W Metal Oxide
R728 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
!
R729 RMPTKA001WJZZ AH J Resistor Packaged Circuit
R730 VRS-TQ2BD393FY AA J Resistor 39k 1/8W Metal Oxide
R731 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R732 VRS-CY1JF270FY AA J Resistor 27 1/16W Metal Oxide
R733 VRS-CY1JF330FY AA J Resistor 33 1/16W Metal Oxide
R735 VRS-CY1JF564JY AA J Resistor 560k 1/16W Metal Oxide
R737 RR-WZA012WJZZ AE J Resistor 0.15 5W
R738 VRN-CY1JF304DY AB J Resistor 300k 1/16W Metal Film
R739 VRN-CY1JF133DY AB J Resistor 13k 1/16W Metal Film
R740 VRN-SV2HC3R9JY AB J Resistor 3.9 1/2W Metal Film
R741 VRN-TV1JD394DY AB J Resistor 390k 1/16W Metal Film
R742 VRS-TQ2EF100JY AA J Resistor 10 1/4W Metal Oxide
R743 VRS-TQ2EF100JY AA J Resistor 10 1/4W Metal Oxide
R744 VRS-TQ2EF101JY AA J Resistor 100 1/4W Metal Oxide
R745 VRS-TQ2EF101JY AA J Resistor 100 1/4W Metal Oxide
R746 VRS-TV1JD103JY AA J Resistor 10k 1/16W Metal Oxide
R747 VRS-TV1JD103JY AA J Resistor 10k 1/16W Metal Oxide
R749 VRN-TV1JD394DY AB J Resistor 390k 1/16W Metal Film
R750 VRN-TV1JD394DY AB J Resistor 390k 1/16W Metal Film
R751 VRN-TV1JD394DY AB J Resistor 390k 1/16W Metal Film
R752 VRN-TV1JD394DY AB J Resistor 390k 1/16W Metal Film
!
R753 RR-HZ0119CEZZY AC J Resistor 270k
R761 VRS-TQ2BD103JY AA J Resistor 10k 1/8W Metal Oxide
R762 VRS-CY1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R766 VRS-TQ2BD000JY AA J Resistor 0 1/8W Metal Oxide
R767 VRS-TQ2BD434FY AB J Resistor 430k 1/8W Metal Oxide
R768 VRS-TQ2BD434FY AB J Resistor 430k 1/8W Metal Oxide
R769 VRS-CY1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R770 VRS-CY1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R771 VRS-CY1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R772 VRS-TQ2BD000JY AA J Resistor 0 1/8W Metal Oxide
R901 VRS-TV1JD334FY AA J Resistor 330k 1/16W Metal Oxide
R902 VRS-TV1JD334FY AA J Resistor 330k 1/16W Metal Oxide
R903 VRS-TV1JD334FY AA J Resistor 330k 1/16W Metal Oxide
R904 VRS-TV1JD334FY AA J Resistor 330k 1/16W Metal Oxide
R905 VRS-TV1JD123FY AA J Resistor 12k 1/16W Metal Oxide
R907 VRS-TQ2EF100JY AA J Resistor 10 1/4W Metal Oxide
R908 VRS-TQ2EF100JY AA J Resistor 10 1/4W Metal Oxide
R909 VRS-TQ2EF100JY AA J Resistor 10 1/4W Metal Oxide
R910 VRS-TQ2EF100JY AA J Resistor 10 1/4W Metal Oxide
R911 VRS-TQ2EF100JY AA J Resistor 10 1/4W Metal Oxide
R912 VRS-TV1JD103JY AA J Resistor 10k 1/16W Metal Oxide
R913 VRS-TQ2EF220JY AA J Resistor 22 1/4W Metal Oxide
R914 VRS-TQ2EF100JY AA J Resistor 10 1/4W Metal Oxide
R917 VRS-TQ2EF181JY AA J Resistor 180 1/4W Metal Oxide
R919 VRS-TQ2EF100JY AA J Resistor 10 1/4W Metal Oxide
R920 VRS-TQ2EF100JY AA J Resistor 10 1/4W Metal Oxide
R921 VRS-TQ2EF100JY AA J Resistor 10 1/4W Metal Oxide
R922 VRS-TQ2EF100JY AA J Resistor 10 1/4W Metal Oxide
R925 VRS-TV1JD224FY AA J Resistor 220k 1/16W Metal Oxide
R926 VRS-TV1JD224FY AA J Resistor 220k 1/16W Metal Oxide
R927 VRS-TV1JD224FY AA J Resistor 220k 1/16W Metal Oxide
[4] DUNTKE392WEF3 (BALLAST POWER Unit)
